BAS20DW-BAS21DW
SURFACE MOUNT HIGH VOLTAGE DUAL SWITCHING DIODE
Features
•
•
•
•
•
•
•
Fast Switching Speed
Surface Mount Package Ideally Suited for Automated Insertion
High Reverse Breakdown Voltage
Low Leakage Current
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Notes 2 and 3)
Qualified to AEC-Q101 Standards for High Reliability
Mechanical Data
•
•
•
•
•
•
Case: SOT363
Case Material: Molded Plastic, “Green” Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminal Connections: See Diagram
Terminals: Finish
⎯
Matte Tin annealed over Alloy 42
leadframe. Solderable per MIL-STD-202, Method 208
Weight: 0.003 grams (approximate)
SOT363
Top View
Top View
Internal Schematic
Ordering Information
(Note 4)
Part Number
BAS20DW-7
BAS20DW-13
BAS20DWQ-13
BAS21DW-7
Notes:
Qualification
Commercial
Commercial
Automotive
Commercial
Case
SOT363
SOT363
SOT363
SOT363
Packaging
3,000/Tape & Reel
10,000/Tape & Reel
10,000/Tape & Reel
3,000/Tape & Reel
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com.
3. Product manufactured with Date Code UO (week 40, 2007) and newer are built with Green Molding Compound. Product manufactured prior to Date
Code UO are built with Non-Green Molding Compound and may contain Halogens or Sb2O3 Fire Retardants.
4. For packaging details, go to our website at http://www.diodes.com.
Marking Information
xxx = Product Type Marking Code:
BAS20DW Marking: KT2 or KT3
BAS21DW Marking: KT3
YM = Date Code Marking
Y = Year (ex: Y = 2011)
M = Month (ex: 9 = September)
xxx YM
xxx YM
Date Code Key
Year
Code
Month
Code
2005
S
Jan
1
2006
T
Feb
2
2007
U
Mar
3
2008
V
Apr
4
2009
W
May
5
2010
X
Jun
6
Jul
7
2011
Y
Aug
8
2012
Z
Sep
9
2013
A
Oct
O
2014
B
Nov
N
2015
C
Dec
D
BAS20DW-BAS21DW
Document number: DS30617 Rev. 11 - 2
1 of 4
www.diodes.com
November 2011
© Diodes Incorporated
BAS20DW-BAS21DW
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Characteristic
Repetitive Peak Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Current
Average Rectified Output Current
Non-Repetitive Peak Forward Surge Current
Repetitive Peak Forward Surge Current
Symbol
V
RRM
V
RWM
V
R
V
R(RMS)
I
FM
I
O
@ t = 1.0μs
@ t = 1.0s
I
FSM
I
FRM
BAS20DW
200
150
106
400
200
2.5
0.5
625
BAS21DW
250
200
141
Unit
V
V
V
mA
mA
A
mA
Thermal Characteristics
Characteristic
Power Dissipation (Note 5)
Thermal Resistance Junction to Ambient Air (Note 5)
Operating and Storage Temperature Range
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
200
625
-65 to +150
Unit
mW
°C/W
°C
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Reverse Breakdown Voltage (Note 6)
Forward Voltage
Reverse Current
@ Rated DC Blocking Voltage (Note 6)
Total Capacitance
Reverse Recovery Time
Notes:
Symbol
BAS20DW
BAS21DW
V
(BR)R
V
F
I
R
C
T
t
rr
Min
200
250
⎯
⎯
⎯
⎯
Max
⎯
⎯
1.0
1.25
100
15
5.0
50
Unit
V
V
nA
μA
pF
ns
Test Condition
I
R
= 100μA
I
F
= 100mA
I
F
= 200mA
T
j
= 25°C
T
j
= 100°C
V
R
= 0, f = 1.0MHz
I
F
= I
R
= 30mA,
I
rr
= 0.1 x I
R
, R
L
= 100Ω
5. Part mounted on FR-4 PC board with recommended pad layout, which can be found on our website at http://www.diodes.com/datasheets/ap02001.pdf.
6. Short duration pulse test used to minimize self-heating effect.
200
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
250
1
P
d
, POWER DISSIPATION (mW)
0.1
150
100
0.01
50
0
-50
0
50
100
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 1 Derating Curve - Total
150
0.001
0
0.2
0.4
0. 6
0.8
1.0
1.2
1.4
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
BAS20DW-BAS21DW
Document number: DS30617 Rev. 11 - 2
2 of 4
www.diodes.com
November 2011
© Diodes Incorporated
BAS20DW-BAS21DW
100
4.0
3.5
C
T
, TOTAL CAPACITANCE (pF)
10
3.0
2.5
2.0
1.5
1.0
0.5
0.0
0
1
0.1
0.01
0.001
0.0001
0
150
200
250
50
100
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 3 Typical Reverse Characteristics
10
30
40
20
V
R
, REVERSE VOLTAGE (V)
Fig. 4 Typical Capacitance vs. Reverse Voltage
Package Outline Dimensions
A
B C
H
K
M
J
D
F
L
SOT363
Dim
Min
Max
A
0.10
0.30
B
1.15
1.35
C
2.00
2.20
D
0.65 Typ
F
0.40
0.45
H
1.80
2.20
J
0
0.10
K
0.90
1.00
L
0.25
0.40
M
0.10
0.22
0°
8°
α
All Dimensions in mm
Suggested Pad Layout
C2
C2
Z
G
C1
Y
X
Dimensions Value (in mm)
Z
2.5
G
1.3
X
0.42
Y
0.6
C1
1.9
C2
0.65
BAS20DW-BAS21DW
Document number: DS30617 Rev. 11 - 2
3 of 4
www.diodes.com
November 2011
© Diodes Incorporated
BAS20DW-BAS21DW
