Naina Semiconductor Ltd.
emiconductor
Features
•
•
•
•
Diffused Series
Industrial grade
Available in Normal and Reverse polarity
Metric and UNF thread type
320NS(R)
Standard Recovery Diodes (Stud and Flat Base Type) 320A
andard
Type),
Electrical Specifications
(T
C
= 25
o
C, unless otherwise noted)
Symbol
I
F(AV)
V
FM
I
FSM
It
2
Parameters
Maximum avg. forward current @ T
C
= 150 C
Maximum peak forward voltage drop @
rated I
F(AV)
Maximum peak one cycle (non-rep) surge
rep)
current @ 10 msec
2
Maximum I t rating (non-rep) for 5 to 10
rep)
msec
o
Values
320
1.35
5100
120000
Units
A
V
A
A sec
2
DO-205AB (DO-9)
DO
Voltage Ratings
(T
C
= 25
o
C, unless otherwise noted)
Type
number
Voltage
Code
10
20
40
60
80
100
120
140
160
V
RRM,
Maximum repetitive peak
reverse voltage
(V)
100
200
400
600
800
1000
1200
1400
1600
V
R(RMS),
Maximum RMS
reverse voltage
(V)
70
140
280
420
560
700
840
980
1120
I
R(AV),
Maximum avg. reverse
leakage current at T
J
Max
(mA)
320NS(R)
15
Thermal & Mechanical Specifications
(T
C
= 25
o
C, unless otherwise noted)
Symbol
R
th(JC)
T
J
T
stg
F
W
Parameters
Maximum thermal resistance, junction to case
Operating junction temperature range
Storage temperature
Mounting torque (non-lubricated threads)
lubricated
Approximate allowable weight
Values
0.18
-5 to 150
50
-5 to 180
50
35
250
Units
o
C/W
o
C
o
C
Nm
g
1
D-95, Sector 63, Noida – 201301, India • Tel: 0120-4205450 • Fax: 0120
4205450
0120-4273653
sales@nainasemi.com • www.nainasemi.com
Naina Semiconductor Ltd.
emiconductor
Package Outline
320NS(R)
ALL DIMENSIONS IN MM
Ordering Table
320
1
NS
2
R
3
120
4
1 – Current Rating =
I
F (AV)
2 – Rectifier Diode
3 – Polarity:
>
None = Normal (Cathode to Stud)
>
R = Reverse (Anode to Stud)
4 – Voltage Code x 10 = V
RRM
(See Voltage Ratings Table)
2
D-95, Sector 63, Noida – 201301, India • Tel: 0120-4205450 • Fax: 0120
4205450
0120-4273653
sales@nainasemi.com • www.nainasemi.com
