COPPERFIELD
®
GXL or GXL (UL) 125°C SAE J-1128
General Purpose Automotive Wire (XLPE)
CONDUCTORS:
INSULATION:
• 20 AWG - 8 AWG Stranded Bare Copper
• Color-Coded Cross-Linked Polyethylene (XLPE)
• -40°C - 125°C/60VDC/25VAC
• Ford ESB-M1L85A*
• Chrysler MS-8900*
HOOK-UP WIRE / AUTOMOTIVE
TEMPERATURE RANGE/
VOLTAGE RATING:
INDUSTRY APPROVALS:
• SAE J-1128
STANDARD COLORS:
• Black
• White
• Red
• Orange
• Yellow
• Green
• Blue
• Brown
• Gray
• Violet
• Green/Yellow
OPTIONS:
• Stripes available upon request (minimums may apply)
• Other copper constructions available upon request
(minimums may apply)
Nominal
Wall
Part
Number
Gauge
Stranding
in.
mm.
in.
Nominal
OD
mm.
Weight
lbs./mft
kg/km
GXL J1128/ESB-MIL85A/MS-8900
F20022
F18021*
F18022
F16014
F14021
F12012
F10004
F08011*
F20069
F18089
F18157
F16053
F14049
F12034
F10019
F08005
20
18
18
16
14
12
10
8
20
18
18
16
14
12
10
8
7/28
16/30
19/.0092
19/29
19/27
19/25
19/23
19/.0285
7/28
16/30
19/.0092
19/29
19/27
19/25
19/23
19/.0285
0.023
0.023
0.023
0.023
0.023
0.026
0.031
0.037
0.023
0.023
0.023
0.023
0.023
0.026
0.031
0.037
0.58
0.58
0.58
0.58
0.58
0.66
0.79
0.94
0.58
0.58
0.58
0.58
0.58
0.66
0.79
0.94
0.086
0.092
0.092
0.103
0.117
0.142
0.179
0.216
0.086
0.092
0.092
0.103
0.117
0.142
0.179
0.216
2.18
2.34
2.34
2.62
2.97
3.61
4.55
5.49
2.18
2.34
2.34
2.62
2.97
3.61
4.55
5.49
6.0
8.0
8.0
11.0
16.0
24.0
37.0
60.0
6.0
8.0
8.0
11.0
16.0
24.0
37.0
60.0
9
12
12
16
24
36
55
89
9
12
12
16
24
36
55
89
UL SAE GXL J1128
Dimensions and weights are nominal and are subject to industry tolerances unless otherwise noted.
*GXL J1128 & ESB-MIL85A Only.
See page 127 for Ordering and Color Code information.
Coleman Cable Inc.
- 117 -
800.323.9355 • www.colemancable.com
