DTA114EM/EE/EUA/ECA/ESA
Taiwan Semiconductor
Small Signal Product
PNP Digital Transistor
FEATURES
- Built-in bias resistors enable the configuration of
an inverter circuit without connecting external input
resistor (see equivalent circuit).
- The bias resistors consist of thin -film resistors with
complete isolation to allow negative biasing of
the input.They also have the advantage of almost
completely eliminating parasitic effects.
- Only the on/off conditions need to be set for
operation,marking device design easy.
- Green compound (Halogen free) with suffix "G"
on packing code and prefix "G" on date code.
SOT523
/SOT323/SOT23
1. IN 2.GUD 3.OUT
3
SOT-723
1. BASE
2
2. EMITTER
3. COLLECTOR
1
TO92S
1.GUD 2.OUT 3.IN
Equivalent Circuit
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Power Dissipation
Supply Voltage
Input Voltage
Output Current
PeakCollectoCurrent
Junction and Storage Temperature Range
Notes : 1. Valid provided that electrodes are kept at ambient temperature
SYMBOL
PD
V
CC
V
IN
I
O
I
C(MAX)
TJ, T
STG
VALUE
EM
100
EE
150
EUA ECA
200
-50
-40½10
-50
-100
-55 to + 150
ESA
300
UNIT
mW
V
V
mA
°C
PARAMETER
Input Voltage
Output Voltage
Input Current
Output Current
DC Current Gain
Input Resistance
Resistance Ratio
Transition Frequency
SYMBOL
V
I(on)
V
I(off)
V
O(on)
I
I
I
O（off)
G
I
R
1
R
2
/R
1
f
T
MIN
-0.5
TYP
MAX
-3
-0.3
-0.88
-0.5
CONDITION
V
O
=-0.3V,I
O
=-10mA
V
CC
=-5V,I
O
=-100μA
I
O
/I
I
=-10mA/-5mA
V
I
=-5V
V
CC=
-50V,V
I
=0
V
O
=-5V,I
O
=-5mA
UNIT
V
V
mA
μA
KΩ
30
7
0.8
10
1
250
13
1.2
V
O
=-10V,I
O
=-5mA,f=100MHz
MHz
Document Number：DS_S1402004
Version : C14
DTA114EM/EE/EUA/ECA/ESA
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
MANUFACTURE
CODE(Note)
DTA114EM
DTA114EE
DTA114EUA
DTA114ECA
PACKING CODE
RM
RN
RV
RU
GREEN COMPOUND
CODE
G
G
G
G
PACKAGE
SOT-723
SOT-523
SOT-323
SOT-23
PACKING
8K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K / 7" Reel
3K /
Box(Ammo)
MARKING
14
14
14
14
A114
E031
DTA114ESA
A3
G
TO-92S
Note : Manufacture special control, if empty means no special control requirement.
EXAMPLE
PREFERRED P/N
DTA114EM RMG
DTA114EM-M0 RMG
PART NO.
DTA114EM
DTA114EM
M0
MANUFACTURE
CODE
PACKING CODE
RM
RM
GREEN COMPOUND
CODE
G
G
DESCRIPTION
Green compound
Green compound
Document Number：DS_S1402004
Version : C14
