SS13M_14

Description
Surface Mount Schottky Barrier
File Size183KB,5 Pages
ManufacturerTaiwan Semiconductor
Websitehttp://www.taiwansemi.com/
Download Datasheet View All

SS13M_14 Overview

Surface Mount Schottky Barrier

SS13M thru SS16M
Taiwan Semiconductor
CREAT BY ART
FEATURES
- Low power loss, high efficiency
- Ideal for automated placement
- Moisture sensitivity level: level 1, per J-STD-020
- Compliant to RoHS Directive 2011/65/EU and
in accordance to WEEE 2002/96/EC
- Halogen-free according to IEC 61249-2-21 definition
Surface Mount Schottky Barrier
- Very low profile - typical height of 0.68mm
MECHANICAL DATA
Case:
Micro SMA
Molding compound, UL flammability classification rating 94V-0
Base P/N with suffix "G" on packing code - Green compound (halogen-free)
Base P/N with prefix "H" on packing code - AEC-Q101 qualified
Terminal:
Matte tin plated leads, solderable per JESD22-B102
Meet JESD 201 class 1A whisker test
with prefix "H" on packing code meet JESD 201 class 2 whisker test
Polarity:
Indicated by cathode band
Weight:
0.006 g (approximately)
Micro SMA
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Marking code
Maximum repetitive peak reverse voltage
Maximum average forward rectified current
Peak forward surge current, 8.3 ms single half sine-wave
superimposed on rated load
Maximum instantaneous forward voltage (Note 1)
@ 0.5A / T
J
=25
@ 0.5A / T
J
=125
@ 1.0A / T
J
=25
@ 1.0A / T
J
=125
Maximum reverse current @ rated VR
@ T
J
=25
@ T
J
=125
@ T
J
=150
Typical junction capacitance (Note 2)
Typical thermal resistance
Operating junction temperature range
Storage temperature range
Note 1: Pulse test with PW=300μs, 1% duty cycle
Note 2: Measured at 1 MHz and Applied Reverse Voltage of 4.0 V D.C.
V
RRM
I
F(AV)
I
FSM
TYP
0.45
V
F
0.35
0.52
0.46
TYP
I
R
5
3
5.3
Cj
R
θJL
R
θJC
R
θJA
T
J
T
STG
50
30
40
125
-55 to +150
-55 to +150
SYMBOL
SS13M
A
30
SS14M
B
40
1
25
MAX
-
-
0.55
0.50
MAX
50
10
-
TYP
0.51
0.46
0.64
0.57
TYP
5
3
6.7
40
O
SS16M
C
60
UNIT
V
A
A
MAX
-
-
0.68
0.60
MAX
50
10
-
μA
mA
mA
pF
C/W
O
O
V
C
C
Document Number: DS_D1406008
Version: J14
