INCHANGE Semiconductor
isc Triacs
Features
·Suitables
for general purpose applications where gate high sensitivity is
required. Application on 4Q such as phase control and static switching.
·Minimum
Lot-to-Lot variations for robust device
performance and reliable operation
ABSOLUTE MAXIMUM RATINGS(Ta=25
℃)
SYMBOL
PARAMETER
MIN
UNIT
BTB04 T/D/S/A
I
T(RMS)
I
TSM
T
j
T
stg
R
th(j-c)
R
th(j-a)
SYMBOL
RMS on-state current (full sine wave)T
j
=95℃
Non-repetitive peak on-state current t
p
=10ms
Operating junction temperature
Storage temperature
Thermal resistance, junction to case
Thermal resistance, junction to ambient
PARAMETER
4
40
110
-45~150
3.2
60
400T/D/S/A
400
400
A
A
℃
℃
℃/W
℃/W
600T/D/S/A
600
600
700T/D/S/A
700
700
UNIT
V
V
V
DRM
V
RRM
Repetitive peak off-state voltage
Repetitive peak reverse voltage
ELECTRICAL CHARACTERISTICS (T
C
=25℃ unless otherwise specified)
SYMBOL
PARAMETER
CONDITIONS
V
R
=V
RRM
,
V
R
=V
RRM
, Tj=110
℃
V
D
=V
DRM
,
V
D
=V
DRM
, Tj=110
℃
MAX
UNIT
I
RRM
I
DRM
Repetitive peak reverse current
Repetitive peak off-state current
Ⅰ-Ⅱ-Ⅲ
Ⅳ
0.01
0.75
0.01
0.75
T
D
5
10
15
1.5
1.65
S
10
10
25
A
10
25
25
5
5
mA
mA
I
GT
Gate trigger current
V
D
=12V; R
L
= 33Ω
mA
I
H
V
GT
V
TM
Holding current
Gate trigger voltage all quadrant
On-state voltage
I
GT
= 0.1A, Gate Open
V
D
=12V; R
L
= 30Ω
I
T
= 5A
15
mA
V
V
isc website
：
www.iscsemi.com
isc & iscsemi
is registered trademark
INCHANGE Semiconductor
isc Triacs
BTB04 T/D/S/A
NOTICE：
ISC reserves the rights to make changes of the content herein the datasheet at any time without
notification. The information contained herein is presented only as a guide for the applications of
our products.
ISC products are intended for usage in general electronic equipment. The products are not designed
for use in equipment which require specialized quality and/or reliability, or in equipment which
could have applications in hazardous environments, aerospace industry, or medical field. Please
contact us if you intend our products to be used in these special applications.
ISC makes no warranty or guarantee regarding the suitability of its products for any particular
purpose, nor does ISC assume any liability arising from the application or use of any products, and
specifically disclaims any and all liability, including without limitation special, consequential or
incidental damages.
