VC850M-H2-TO46FW
v 3.1 15.05.2014
Description
VC850M-H2-TO46FW
is a multi mode infrared VCSEL emitting at typically 850 nm with rated output
power of 20 mW cw, mounted into a standard TO-46 package and sealed with a flat window cap. The
VCSEL works under low forward current and voltage.
Maximum Ratings
Parameter
Forward Current
Reverse Voltage (@ 10µA)
Operating Temperature
Storage Temperature
Lead Solder Temperature *
* must be completed within 10 seconds
Symbol
I
F
V
F
T
CASE
T
STG
T
SLD
0
- 40
Values
Min.
Max.
70
5
+ 60
+ 100
+ 260
Unit
mA
V
°C
°C
°C
Electro-Optical Characteristics
Parameter
Emission Wavelength
Spectral Width
Optical Output Power
Threshold Current
Operating Current
Operating Voltage
Breakdown Voltage
Slope Efficiency
Dynamic Resistance
Symbol
(T
CASE
=25°C)
Values
Typ.
850
20
15
50
2.1
-10
0.4
10
Unit
nm
nm
mW
mA
mA
V
V
mW/mA
Ω
Min.
840
18
Max.
860
0.85
λ
Peak
∆λ
P
O
I
TH
I
F
V
F
V
B
η
R
D
2.6
0.2
20
Thermal Characteristics
Parameter
I
TH
Temperature Variation
η Temperature Variation
λ Temperature Variation
Symbol
ΔI
TH
Δη / ΔT
Δλ / ΔT
Min.
Values
Typ.
10
-0.5
0.06
Max.
Test Conditions
T
C
=0 to 60°C
T
C
=0 to 60°C,50mA
T
C
=0 to 60°C,50mA
Unit
mA
%/°C
nm/°C
www.roithner-laser.com
1
Optical Output Power vs. Temperature
Threshold Current vs. Temperature
Spectral Emission
FFP
Precautions
Static Electricity:
VCSELs are
sensitive to electrostatic discharge (ESD).
Precautions against ESD must be taken
when handling or operating these VCSELs. Surge voltage or electrostatic discharge can result in
complete failure of the device.
Safety Advice:
This VCSEL emits concentrated infrared light which can be
hazardous to the human eye and skin.
This diode is classified as CLASS 3B laser product according to
IEC 60825-1
and
21 CFR Part
1040.10
Safety Standards.
Operation:
Do
only
operate VCSELs with a current source.
Running these LEDs from a voltage source will result in complete failure of the device.
Current of a LED is an exponential function of the voltage across it. Usage of current regulated drive
circuits is mandatory.
© All Rights Reserved
The above specifications are for reference purpose only and subjected to change without prior notice
www.roithner-laser.com
3
