227HSM035KCC datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Passive components> capacitor> 227HSM035KCC

Preview

227HSM035KCC: DescriptionAluminum Electrolytic Capacitor, Aluminum (wet); CategoryPassive components capacitor; File Size509KB，3 Pages; ManufacturerIllinois Capacitor; Websitehttp://www.illinoiscapacitor.com/; Environmental Compliance

Download Datasheet Parametric View All

227HSM035KCC Overview

Aluminum Electrolytic Capacitor, Aluminum (wet)

227HSM035KCC Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Illinois Capacitor
package instruction	,
Reach Compliance Code	compliant
ECCN code	EAR99
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
dielectric materials	ALUMINUM (WET)
JESD-609 code	e3
Number of terminals	2
Terminal surface	Matte Tin (Sn)

Preview

Download Datasheet

View All

HSM

FEATURES

+125°C Standard

Radial Lead

Aluminum Electrolytic

Capacitors

For automotive and telecommunication applications

I

125°C Temperature rating

I

Extended Life

I

Voltage range: 10 WVDC to 63WVDC

I

Capacitance Range: 1.0µF to 4,700µF

SPECIFICATIONS

Capacitance Tolerance

Operating Temperature Range

Dissipation Factor

120Hz, 20°C

WVDC

tan

δ

10

.2

±20% at 120Hz, 20°C

-40°C to +125°C

16

.16

25

.14

35

.12

50

.1

63

.1

Note:

For above D.F. specifications, add .02 for every 1,000 µf above 1,000 µf

WVDC

Impedance Ratio

(Max.) @120Hz

-25/20°C

-40/20°C

WVDC

Leakage Current

Time

10

3

4

16

2

4

25

2

4

35

2

4

50

2

4

63

2

4

≤

63WVDC

1 minute

.03 CV or 4 µA

2 minutes

.01 CV or 3 µA

Whichever is greater

1,000 hours at 125°C with rated WVDC

Load Life

Capacitance change

Dissipation factor

Leakage current

< 20% of initial measured value

<200% of initial specified value

<100%Initial specified value

1,000 hours at 105°C with no voltage applied.

Units will meet load life specification.

Shelf Life

Frequency(Hz)

Ripple Current Multipliers

Capacitance (µF)

C≤47

47<C≤470

C>470

50

.75

.8

.85

120

1.0

300

1.35

1.23

1.1

1K

1.57

1.34

1.13

10K

2

1.5

1.15

Temperature(°C)

+105

1.00

+85

1.4

+70

1.65

SPECIAL ORDER OPTIONS

•

Special tolerances: ±10% (K), -10% + 30% (Q)

•

(See pages 33 thru 37)

Tape and Reel/Ammo Pack

•

Cut, Formed, Cut and Formed, and Snap In Leads

®

3757 W. Touhy Ave., Lincolnwood, IL 60712 • (847) 675-1760 • Fax (847) 673-2850 • www.illcap.com
