SMD LED LAMP
BL-LS3806A0S1
Features:
3.8mmx0.6mm SMD, 1.2mm THICKNESS side emitting
Mono-color type, Ultra brightness
Compatible with automatic placement equipment
WIDE VIEWING ANGLE.
IDEAL FOR BACKLIGHT AND INDICATOR.
PACKAGE: 2KPCS/REEL
RoHs Compliance
Electrical-optical characteristics: (Ta=25°C)
Chip
(Test Condition: IF=20mA)
Luminous
Intensity
(Iv)
Unit:mcd
Part Number
Emitted Color
Material
P
(n
m)
Lens
Type
Forward
Voltage(VF)
Unit:V
Viewi
ng
Angle
2θ1/2
(deg)
Typ
BL-LS3806A0S1UEC
BL-LS3806A0S1UYO
BL-LS3806A0S1UYC
BL-LS3806A0S1UGC
BL-LS3806A0S1PGC
BL-LS3806A0S1UBC
BL-LS3806A0S1UWC
Ultra Red
Ultra Amber
Ultra Yellow
Ultra Green
Ultra Pure Green
Ultra Blue
Ultra White
AlGaAs
AlGaInP
AlGaInP
AlGaInP
InGaN
InGaN
InGaN
630
610
593
575
525
470
/
Water
Clear
2.10
2.10
2.10
2.20
3.10
3.10
3.10
Max
2.50
2.60
2.60
2.70
3.80
3.80
3.80
Min.
250
500
500
70
1300
450
1900
Typ.
320
600
600
80
1500
500
2100
120
Absolute maximum ratings (Ta=25°C)
Unit
Parameter
UE
UYO
UY
UG
PG
UB
UW
Forward Current I
F
Power Dissipation P
d
Reverse Voltage V
R
Peak Forward Current I
PF
(Duty 1/10 @1KHZ)
Operation Temperature T
OPR
Storage Temperature T
STG
Lead Soldering Temperature
T
SOL
30
78
5
100
30
78
5
100
30
78
5
100
30
78
5
100
-30 to +80
-40 to +85
30
78
5
100
30
78
5
100
30
78
5
100
mA
mW
V
mA
°C
°C
Max.260±5°C for 3 sec Max.
(1.6mm from the base of the epoxy bulb)
°C
APPRO
VED : XU L CHECKED :ZHANG WH DRAWN: LI FS
REV NO: V.4
Page 1 of 8
WWW.BETLUX.COM
EMAIL:
SALES@BETLUX.COM
,
BETLUX@BETLUX.COM
SMD LED LAMP
BL-LS3806A0S1
Package configuration & Internal circuit diagram
BL-LS3806A0S1
Notes:
1. All dimensions are in millimeters (inches)
2. Tolerance is ±0.25(0.01")unless otherwise noted.
3. Specifications are subject to change without notice.
APPRO
VED : XU L CHECKED :ZHANG WH DRAWN: LI FS
REV NO: V.4
Page 2 of 8
WWW.BETLUX.COM
EMAIL:
SALES@BETLUX.COM
,
BETLUX@BETLUX.COM
SMD LED LAMP
BL-LS3806A0S1
Tape Specifications
Smt Reflow Solding Instructions
Number of reflow process shall be less than 2 times
and cooling process to normai temperature is required
between first and second soldering process
Recommended Soldering Pattern
(Units:mm)
1.60
2.10
1.60
1.10
Tape Specifications
(Units:mm)
Cathode mark
?1.50
4.00
2.00
1.75
1.0
5.50
12.00
5.8
4.00
APPRO
VED : XU L CHECKED :ZHANG WH DRAWN: LI FS
REV NO: V.4
Page 3 of 8
WWW.BETLUX.COM
EMAIL:
SALES@BETLUX.COM
,
BETLUX@BETLUX.COM
SMD LED LAMP
BL-LS3806A0S1
SELECTION CODE FOR SUPER BRIGHT LEDS
brightness(mcd)@20mA
brightness(mcd)@20mA
Group
Group
min
max
min
max
D
50
80 L
550
E
80
120 M
750
F
120
170 N
1000
G
170
230 P
1300
H
230
300 Q
1700
J
300
400 R
2200
K
400
550 S
3000
750
1000
1300
1700
2200
3000
4000
forward voltage Ranks
Voltage (V)
Group
Group
min
max
A
1.7
1.9 K
B
C
D
E
F
G
H
J
1.9
2.1
2.3
2.5
2.8
3
3.2
3.4
2.1 L
2.3 M
2.5 N
2.8 P
3 Q
3.2 R
3.4 S
3.6 T
Voltage (V)
min
max
3.6
3.8
4
4.2
4.4
4.6
4.8
5
5.2
3.8
4
4.2
4.4
4.6
4.8
5
5.2
5.4
APPRO
VED : XU L CHECKED :ZHANG WH DRAWN: LI FS
REV NO: V.4
Page 4 of 8
WWW.BETLUX.COM
EMAIL:
SALES@BETLUX.COM
,
BETLUX@BETLUX.COM
SMD LED LAMP
BL-LS3806A0S1
Color Temperature Bin
