YAGEO CORPORATION
ELECTROLYTIC CAPACITORS
Miniature Aluminum
Electrolytic Capacitors
SU
[ For Higher Temperature Range ]
125°C 2000 Hours, High Temperature
ELECTRICAL CHARACTERISTICS
Operating Temperature Range : -40 ~ +125°C
Rated Voltage Range : 10 ~ 63VDC
Rated Capacitance Range : 4.7 ~ 4700µF
Capacitance Tolerance : ±20% at 120Hz, 20°C
DESCRIPTION
Applicable for Electronic Ballast, Lighting Ballast
MULTIPLIER FOR RIPPLE CURRENT
FREQUENCY (Hz)
Cap ≤ 10µF
10µF < Cap ≤ 100µF
1,000µF < Cap
120 1K
10K 50K~100K
1.00 1.45 1.65 1.70
1.00 1.36 1.48 1.53
1.00 1.17 1.25 1.28
Leakage Current (Max.) (20°C): I = 0.01CV or 3µA whichever is greater.
(After Rated Voltage Applied for 2 Minutes)
I = Leakage Current (µA), C = Nominal Capacitance (µF), V = Rated Voltage (V)
Dissipation Factor (Max.) (tanδ) (120Hz, 20°C)
W V (V) :
D.F. (%) :
1000µF.
Low Temperature Stability Impedance Ratio (Max.)
W V (V) :
Z-25°C/Z+20°C :
Z-25°C/Z+20°C :
10
3
6
16
2
4
25
2
4
35
2
4
50
2
4
63
2
4
10
0.20
16
0.16
25
0.14
35
0.12
50
0.10
63
0.09
When nominal capacitance is over 1000µF, the value of tanδ shall be increased by 0.02 for every addition of
100µF < Cap ≤ 1,000µF 1.00 1.25 1.35 1.38
Endurance: After the rated voltage and rated ripple current have been applied at 125°C for 2000 hours, the
capacitors shall meet the following requirements.
(a) Capacitance Change: Within ±30% of Initial Value
(b) Dissipation Factor: 300% or Less of Initial Specified Value
(c) Leakage Current: Initial Specified Value or Less
Shelf Life: After leaving capacitors under no load at 125°C for 1000 hours.
(a) Capacitance Change: Within ±30% of Initial Value
(b) Dissipation Factor: 300% or Less of Initial Specified Value
(c) Leakage Current: 500% or Less of Initial Specified Value
DIAGRAM OF DIMENSIONS
Dø
Vinyl Sleeve
Rubber End Seal
dø
F
±
0.5
F
±
0.5
Dø
±
0.5
Dimensions: mm
F
1.5
dø
0.5
5.0
6.3
8.0
10.0
0.6
L
15Min.
4Min.
Dø
<
20 Dø + 0.5
Dø
≥
20 Dø + 1
13.0
16.0
2.0
0.8
93
CASE SIZE & PERMISSIBLE RIPPLE CURRENT OF STANDARD PRODUCTS
CAP. (μF)
RATED VOLTAGE W V (SURGE VOLTAGE W V)
10 (13)
SIZE
4.7
10
22
33
47
100
150
220
330
470
1000
2200
3000
4700
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 25
16 x 25
16 x 32
92
145
210
300
410
510
1070
1100
1200
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 20
16 x 25
16 x 32
92
145
210
300
410
510
740
1100
1200
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 20
16 x 25
16 x 32
92
145
210
300
410
510
740
1100
1200
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 20
16 x 25
16 x 32
92
145
210
300
410
510
740
1100
1200
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 20
13 x 25
16 x 25
16 x 32
92
145
210
300
410
510
740
1070
1100
1200
RIPPLE
16 (20)
SIZE
RIPPLE
25 (32)
SIZE
RIPPLE
35 (44)
SIZE
RIPPLE
50 (63)
SIZE
RIPPLE
63 (79)
SIZE
5 x 11
6.3 x 11
8 x 11
10 x 12
10 x 15
10 x 19.5
13 x 20
13 x 25
16 x 25
16 x 32
D x L: mm
RIPPLE
92
145
210
300
410
510
740
1070
1100
1200
Note: 1. Ripple Current: (mA/rms) 125°C, 120KHz
