Reverse protection diode fitted in all voltage models
Range of LED colour options
Range of voltage options
BENEFITS
•
•
•
•
•
•
•
•
•
•
Flush styling
Suitable for harsh environments
Suitable for external applications
Diffused lens gives wide viewing angle
Suitable for high vibration applications
Protects against wrong polarity installation (voltage models)
Suitable for status panel indication
Manufactured with internal resistor
Outstanding reliability
Vandal resistant
Marl Part
Number
520-301-04
520-325-04
520-324-04
520-934-04
520-998-04
520-301-20
520-325-20
520-324-20
520-934-20
520-998-20
520-301-21
520-325-21
520-324-21
520-934-21
520-998-21
520-301-23
520-325-23
520-324-23
520-934-23
520-998-23
520-301-24
520-325-24
520-324-24
520-934-24
520-998-24
LED Colour
Red
Yellow
Green
Blue
Cool White
Red
Yellow
Green
Blue
Cool White
Red
Yellow
Green
Blue
Cool White
Red
Yellow
Green
Blue
Cool White
Red
Yellow
Green
Blue
Cool White
Typical Voltage
DC Vopr
1.85 **
2.0 **
3.2 **
3.2 **
3.2 **
5-6
5-6
5-6
5-6
5-6
12
12
12
12
12
24-28
24-28
24-28
24-28
24-28
48
48
48
48
48
Vdc
Typical Current
DC Iopr
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
15
15
15
15
15
12
12
12
12
12
mA
Typical LED
Luminous
Intensity
33
401
1010
225
1194
33
401
1010
225
1194
33
401
1010
225
1194
27
308
830
175
932
18
208
615
125
648
mcd
Typical LED
Wavelength
λp
640
590
525
471
See Below
640
590
525
471
See Below
640
590
525
471
See Below
640
590
525
471
See Below
640
590
525
471
See Below
nm
Operating
Temp
Topr *
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
-40 to +75
°C
Storage
Temp
Tstg
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
-40 to +100
°C
Typical Emission Colours Cool White LED
X
Y
0.292
0.286
0.285
0.300
0.330
0.350
0.330
0.329
OPTIONAL FLYING LEAD TERMINATORS
Marl Part No
Suffix
520-301-04-15
520-301-04-19
Wire Length
150mm
1000mm
Wire Colour
Red - Anode
Black - Cathode
No/Diameter of
Conductors
19/0.16mm
Diameter of Insulation Wire Specification
1.2mm
Type 44, 22 Gauge
High Performance Wire
NOTES
Intensities (lv) and colour shades of white (X-Y co-ordinates) may vary between LEDs within a batch. Additional LED Colours, Voltage Options and Flying Lead lengths available for semi-
custom projects. Please contact our Sales Team. All LED components are supplied in anti-static packaging.
* For operating temperature derating graphs, please refer to sheet 2.
** These are Current models and the voltage shown is Vf at 20mA, not Vopr. Additionally, there is no reverse protection diode in Current models.
To order please contact us on +44 (0) 1229 582 430
F +44 (0) 1229 585 155
|
E sales@marl.co.uk
| www.leds.co.uk
marlleds
marlinternationallimited
company/marl-international-limited
Q 05480
DSN 520 Version 2014-09-26-082400. Page 1 of 2
520 SERIES
PANEL INDICATOR LED
TECHNICAL CHARACTERISTICS
Series
520
Max. Power
Dissipation
500
mW
Max. Reverse
Voltage
3*/1000^
Vdc
Panel Cutout
6.1
mm
Nut Mounting
Torque
0.65
Nm
Min. Mounting
Centres
15.0
mm
Min - Max. Panel
Thickness
3.0 - 6.5
mm
* = Current version ^ = Voltage version
TECHNICAL DRAWING
Weight (g): 10.0
Dimensions in mm (typical). Not to scale. Mounting hole to be clean and burr free. Anode termination indicated by long pin.
*
45.0
0°
24
10
PUSH ON CONNECTOR
11.8
12.5
12
2.54 Ctrs
0.5 Sq
Sealing Ring
DE-RATING GRAPHS
Forward Current If (mA)
Forward Current If (mA)
Forward Current If (mA)
Forward Current If (mA)
50
40
30
20
10
0
Red LED
6.1
Panel Seal
909-000-00 is gold plated, 910-000-00 is tin plated - for use
with 520 series lamps.
Dimensions in mm (typical). Not to scale.
+
0.1
0
50
40
30
20
10
0
Yellow LED
50
40
30
20
10
8.5
Blue / Green LED
50
40
30
20
10
8.5
Cool White LED
0
20
40
60
80
100
0
20
40
60
80
100
0
0
20
40
60
80
100
0
0
20
40
60
80
100
Ambient Temperature Ta (°C)
Ambient Temperature Ta (°C)
Ambient Temperature Ta (°C)
Ambient Temperature Ta (°C)
MATERIALS
Body
Nut
Panel Seal
Lens
Encapsulation
Lock Washer
Termination
Stainless Steel Grade 303
Stainless Steel Grade 303
Nitrile
Polycarbonate
Black Polyurethane
Stainless Steel
Phosphor bronze with tin on nickel finish
DESIGN CONSIDERATIONS
Electro-Static Discharge (ESD)
Build up of electro-static discharge occurs in many situations
involving people moving and handling products.The range
of possible situations is very diverse but voltage levels as
high as several thousand volts can and do arise in many
individual situations. When an operator charged up to these
levels handles a static sensitive device, there is a very
probable likelihood that the device will be irreversibly
damaged. It is essential that precautions are taken at all
stages during manufacture and assembly of these products.
Although LEDs were never considered to be static sensitive
devices, changes in manufacturing technology and
materials used to produce higher intensity products over a
large range of the wavelength spectrum have changed this.
Marl has an approved system of ESD control from goods
in, through production and into final packing and despatch.
Marl recommend all users of LED based products follow the
guidelines of BS 100015.
Voltage, Current and Temperature
The forward voltage / current value of an LED is dependent
upon the ambient temperature of the environment in which
it is operated. Therefore, care must be taken to operate the
LED at the correct voltage / current values, depending upon
the ambient temperature.
Marl should be contacted if the device is to be operated
outside the temperature range specified. Marl accept no
liability for any product that is operated outside the stated
voltage or temperature range.
