BCR16RM-12LB
Parameter
RMS on-state current
Surge on-state current
I
2
t for fusing
Peak gate power dissipation
Average gate power dissipation
Peak gate voltage
Peak gate current
Junction temperature
Storage temperature
Mass
Isolation voltage
Notes: 1. Gate open.
Symbol
I
T (RMS)
I
TSM
I
2
t
P
GM
P
G (AV)
V
GM
I
GM
Tj
Tstg
—
Viso
Ratings
16
160
128
5
0.5
10
2
– 40 to +150
– 40 to +150
5.2
2000
Unit
A
A
A
2
s
W
W
V
A
°C
°C
g
V
Conditions
Commercial frequency, sine full wave
360° conduction, Tc = 117°C
50 Hz sinewave 1 full cycle, peak value,
non-repetitive
Value corresponding to 1 cycle of half
wave 50 Hz, surge on-state current
Typical value
Ta = 25°C, AC 1 minute,
T
1
·T
2
·G terminal to case
Electrical Characteristics
Parameter
Repetitive peak off-state current
On-state voltage
Gate trigger voltage
Note2
Ι
ΙΙ
ΙΙΙ
Ι
ΙΙ
ΙΙΙ
Symbol
I
DRM
V
TM
V
FGT
Ι
V
RGT
Ι
V
RGT
ΙΙΙ
I
FGT
Ι
I
RGT
Ι
I
RGT
ΙΙΙ
V
GD
R
th (j-c)
(dv/dt)c
Min.
—
—
—
—
—
—
—
—
0.2/0.1
—
10/1
Typ.
—
—
—
—
—
—
—
—
—
—
—
Max.
2.0
1.5
1.5
1.5
1.5
30
30
30
—
1.8
—
Unit
mA
V
V
V
V
mA
mA
mA
V
°C/W
V/µs
Test conditions
Tj = 150°C, V
DRM
applied
Tc = 25°C, I
TM
= 25 A,
Instantaneous measurement
Tj = 25°C, V
D
= 6 V, R
L
= 6
Ω,
R
G
= 330
Ω
Tj = 25°C, V
D
= 6 V, R
L
= 6
Ω,
R
G
= 330
Ω
Tj = 125°C/150°C, V
D
= 1/2 V
DRM
Junction to case
Note3
Tj = 125°C/150°C
Gate trigger current
Note2
Gate non-trigger voltage
Thermal resistance
Critical-rate of rise of off-state
Note4
commutating voltage
Notes: 2. Measurement using the gate trigger characteristics measurement circuit.
3. The contact thermal resistance R
th (c-f)
in case of greasing is 0.5°C/W.
4. Test conditions of the critical-rate of rise of off-state commutating voltage is shown in the table below.
Commutating voltage and current waveforms
(inductive load)
Supply Voltage
Time
(di/dt)c
Time
Test conditions
1. Junction temperature
Tj = 125°C/150°C
2. Rate of decay of on-state commutating current
(di/dt)c = – 8.0 A/ms
3. Peak off-state voltage
V
D
= 400 V
Main Current
Main Voltage
(dv/dt)c
Time
V
D
REJ03G1714-0100 Rev.1.00 Jul 08, 2008
Page 2 of 7
