RCR
anti-surge power type leaded resistor
EU
features
•
Excellent anti-surge characteristics
•
Stable characteristics of moisture resistance
up to high resistance range
•
RCR50 +(1MΩ - 12MΩ), RCR50EN (1MΩ - 12MΩ) and
RCR60 (1MΩ - 12MΩ) are discharge resistors recognized
by UL1676 and c-UL(CSA-C22.2 No.1-M94)
•
RCR25EN (100kΩ~33MΩ), RCR50EN (100kΩ - 33MΩ) and
RCR60 (100kΩ - 56MΩ) is approved by EN6234-68-1 G.10 safety
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
Surface mount style “N” forming is suitable for automatic mounting
leaded
resistors
dimensions
and construction
L
t
D
Trimming Line
Ceramic Core
t
d
l
Type
RCR16
RCR25
RCR25EN
RCR50(+)
RCR50EN
RCR60
RCR75
L
.126±.008
(3.2±0.2)
.248±.02
(6.3±0.5)
.374±.039
(9.5±1.0)
.374
+.039
-.004
(9.5
+1.0
)
-0.2
.472±.039
(12±1.0)
Dimensions
inches
(mm)
D
d (nom.)
C (max.) t (max.)
.134
(3.4)
.28
(7.1)
—
—
.067
+.008
-.004
(1.7
+0.2
)
-0.1
.098±.02
(2.5±0.5)
.138±.016
(3.5±0.4)
.157±.02
(4.0±0.5)
.236
+.039
-.016
(6.0
+1.0
)
-0.4
105
Nominal
Resistance
2 significant
figures + 1
multiplier for ±5%
3 significant
figures + 1
multiplier for ±1%
l*
.018
(0.45)
.024
(0.6)
.028
(0.7)
.031
(0.8)
.031
(0.8)
J
Tolerance
F: ±1%
J: ±5%
.787 Min.
(20.0 Min.)
—
Marking
Resistive
Film
End
Cap
Lead
Wire
.118
(3.0)
.118
(3.0)
.118
(3.0)
A
Flame Retardant Coating
C
—
—
* Lead length changes depending on taping and forming.
ordering information
RCR
Type
RCR
50
Power
Rating
16: 0.25W
25: 0.25W
50: 0.5W
60: 1W
75: 2W
100: 3W
RCR100
.610±.039
(15.5±1.0)
T52
EN
Safety Appr.
Marking
RCR50+: +
RCR25EN,
RCR50EN: EN
Blank: Others
C
Termination
Material
C: SnCu
Taping and Forming
RCR16: T26, T52
RCR25, RCR25EN: T26,
T52
RCR50(+, EN): T52
RCR60: T52
RCR75: T52
RCR100: T521, T631
L, M, N Forming
Packaging
A: Ammo
R: Reel
TEB: Plastic
embossed:
N forming
applications and ratings
Part
Designation
RCR16
RCR25
RCR25EN
RCR50
RCR50+
RCR50EN
RCR60
RCR75
RCR100
1.0W
2.0W
3.0W
1000V
0.5W
700V
0.25W
Power
Rating
@ 70°C
Minimum
Dielectric
Withstanding
Voltage
300V
Resistance
Range
E-24, E-96
(F±1%)
100kΩ - 5.1MΩ
100kΩ - 9.1MΩ
3.3Ω - 910kΩ
1MΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
100kΩ - 9.1MΩ
Resistance
Range
E-24
(J±5%)
100kΩ - 5.1MΩ
100kΩ - 33MΩ
3.3Ω - 910kΩ
13MΩ - 33MΩ
1MΩ - 12MΩ
100kΩ - 33MΩ
100kΩ - 56MΩ
100kΩ - 100MΩ
100kΩ - 51MΩ
Absolute
Maximum
Working
Voltage
500V
DC 1600V
AC 1150V
Absolute
Maximum
Overload
Voltage
1000V
DC 2000V
AC 1500V
Operating
Temperature
Range
2000V
2500V
-55°C to +155°C
4000V
5000V
5000V
For further information on packaging, please refer to Appendix C.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/29/18
172
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
RCR
anti-surge power type leaded resistor
environmental applications
Derating Curve
100
80
% Rated Power
60
40
20
0
-60 -40 -20
-55
Notice of Surge Load
Surge withstanding load voltage for the resistors cannot be guaranteed when the
undermentioned 4 items get to a remarkable overload in comparison with the
conditions shown by surge withstanding voltage in Anti-surge characteristics.
Please contact KOA in advance if such a case is anticipated.
10kV
1. Peak voltage to be applied
2. Pulse width
3. Conditions of protecting insulation around the resistor
Discharge
About 5mm
4. Situation of proximity conductivity object
0
For resistors operated at an ambient temperature
of 70°C or above, a power rating shall be derated
in accordance with the above derating curve.
Approvals Awarded
UL1676 & c-UL
EN60065 14.1 EN62368-1
(CSA-C22.2 No.1-M94)
Test a Test b
G.10
Type
RCR25EN
—
—
m
m
RCR50+
—
—
—
m(1MΩ~12MΩ)
RCR50EN
m
m
m
RCR60
m
m
m
Performance Characteristics
Parameter
Resistance
Requirement
∆
R ±(% + 0.05Ω)
Limit
Within regulated tolerance
Type
T.C.R.
Resistance Range
RCR16
±200ppm/°C 100kΩ - 5.1MΩ
RCR25 (EN) ±350ppm/°C
100kΩ - 33MΩ
±500ppm/°C
3.3Ω - 91kΩ
RCR50 (+)
±350ppm/°C
100kΩ - 33MΩ
RCR50EN ±350ppm/°C
100kΩ - 33MΩ
RCR60
±350ppm/°C
100kΩ - 56MΩ
±350ppm/°C 100kΩ - 100MΩ
RCR75
RCR100
±200ppm/°C 100KΩ - 51MΩ
1%
1%
No mechanical damage
1%
5%
5%
No visible damage to protective coating
and marking
Typical
Test Method
—
Measuring points are 10mm ± 1mm from the end cap
T.C.R.
—
+25°C/+125°C
Overload
Resistance to Solder Heat
Terminal Strength
Rapid Change of Temperature
Moisture Resistance
Endurance @ 70°C
Resistance to Solvent
0.5%
0.5%
—
0.5%
2.5%
2.5%
—
Rated voltage x 2.5 or maximum overload voltage
for 5 seconds, whichever is less
260°C ± 5°C, 10 seconds ± 1 second or 350°C ± 10°C,
3.5 seconds ± 0.5 seconds
Twist 360°, 5 times
-55°C (30 minutes)/+155°C (30 minutes), 5 cycles
40°C ± 2°C, 90-95% RH, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
RCR16, 25, 50 (+), 60: W; RCR75, 100: Wx0.1
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
Isopropyl alcohol with ultrasonic washing, 2 minutes
Power: 0.3W/cm
2
, f: 28kHz, Temperature: 35°C ± 5°C
Discharge test: 2kV - 10kV, 0.01µF capacitor discharge
pulse, 10 times (1 pulse/5 seconds maximum)
Type RCR16
RCR25EN
RCR50, RCR50+
RCR25
RCR50EN,
RCR60, RCR75,
RCR100
Surge Withstanding
10%
2.5%
Applied
Voltage
2kV
3kV
3.3Ω - 6.2Ω: 10kV
6.8Ω - 10Ω: 7kV
11Ω - 9.1kΩ: 5kV
10kΩ - 91kΩ: 7kV
100kΩ - 33MΩ: 10kV
10kV
EN60065 Test
(RCR50EN, RCR60 only)
20%
—
Discharge test: 10kV, 1000pF capacitor discharge pulse,
50 times (1 pulse/5 seconds maximum)
10/29/18
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
173
leaded
resistors
80 100 120 140 160
70
155
Ambient Temperature
(°C)
20
40
60
For example: In the figure, a metal wire is placed
less than 5mm away from the resistor body, there is such a case that causes an
electric discharge by a surge load 10kV and then destroys the outer coating.
Metal Wire
