SMF501C ~ SMF507C
Elektronische Bauelemente
50 V ~ 1000 V
5.0 Amp Surface Mount Silicon
Fast Recovery Rectifiers
RoHS Compliant Product
A suffix of “-C” specifies halogen-free and RoHS Compliant
FEATURES
SMC
Surface mount device
High surge current capability
Low reverse current
Component in accordance to RoHS 2002/95/EC
B
A
C
MECHANICAL DATA
Cases：DO-214AB(SMC)
Case Material：Molded Plastic. UL Flammability
Classification Rating 94V-0
Terminals：Lead Free Plating(Tin Finish)
Solderable Per MIL-STD-202, Method 208
Polarity：Cathode Band
Weight：0.231 grams(approximate)
REF.
A
B
C
D
H
D
G
E
F
REF.
E
F
G
H
Millimeter
Min.
Max.
-
0.203
7.750
8.130
0.760
1.520
0.150
0.305
PACKAGE INFORMATION
Package
SMC
MPQ
3K
Leader Size
13’ inch
Millimeter
Min.
Max.
2.750
3.250
6.520
7.110
5.590
6.220
2.000
2.620
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(Rating 25°C ambient temperature unless otherwise specified. Single phase half wave, 60Hz, resistive or inductive load.
For capacitive load, de-rate current by 20%.)
Part Number
Parameter
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak Forward Surge Current, 8.3ms single
half sine-wave superimposed on rated load
Maximum Instantaneous Forward Voltage
@ 5.0A
Maximum DC Reverse Current T
A
=25°C
at Rated DC Blocking Voltage T
A
=100°C
Typical Junction Capacitance
1
Maximum Reverse Recovery Time
2
Thermal Resistance, Junction to Ambient
Storage and Operating Temperature Range
Symbol
V
RRM
V
RMS
V
DC
I
F
I
FSM
V
F
I
R
C
J
Trr
R
θJA
T
STG
, T
J
SMF
501C
SMF
502C
SMF
503C
SMF
504C
SMF
505C
SMF
506C
SMF
507C
Unit
V
V
V
A
A
V
μA
pF
50
35
50
100
70
100
200
140
200
400
280
400
5
100
1.3
10
100
50
600
420
600
800
560
800
1000
700
1000
150
50
-55~150
250
500
ns
°C / W
°C
Notes:
1. Measured at 1.0MHz and applied reverse voltage of 4.0V D.C.
2. Measured with IF=0.5A, IR=1A, IRR=0.25A.
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
24-May-2011 Rev. B
Page 1 of 2
