POWER SURFACE MOUNT
SMP5025
SMP5025LF*
Molded Unshielded Inductor
RECOMMENDED FOOT PRINT
0.490/0.510
(12.45/12.95)
0.210/0.230
(5.33/5.84)
OVER TERMINAL
PART
NUMBER
SMP5025-101K
SMP5025-121K
SMP5025-151K
SMP5025-181K
SMP5025-221K
SMP5025-271K
SMP5025-331K
SMP5025-391K
SMP5025-471K
SMP5025-561K
SMP5025-681K
SMP5025-821K
SMP5025-102K
SMP5025-122K
SMP5025-152K
SMP5025-182K
SMP5025-222K
SMP5025-272K
SMP5025-332K
SMP5025-392K
SMP5025-472K
SMP5025-562K
SMP5025-682K
SMP5025-822K
SMP5025-103K
SMP5025-123K
SMP5025-153K
SMP5025-183K
SMP5025-223K
SMP5025-273K
SMP5025-333K
SMP5025-393K
SMP5025-473K
SMP5025-563K
SMP5025-683K
SMP5025-823K
SMP5025-104K
SMP5025-124K
SMP5025-154K
SMP5025-184K
SMP5025-224K
SMP5025-274K
SMP5025-334K
SMP5025-394K
SMP5025-474K
SMP5025-564K
SMP5025-684K
SMP5025-824K
SMP5025-105K
L µH
@
1
kHz
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
DCR
MAX
FERRITE CORE
0.015
0.017
0.020
0.023
0.029
0.030
0.035
0.038
0.043
0.046
0.053
0.058
0.071
0.079
0.089
0.109
0.150
0.170
0.222
0.250
0.330
0.370
0.418
0.468
0.620
0.684
0.900
1.04
1.16
1.63
1.82
2.05
2.70
2.80
4.10
4.70
5.40
8.30
9.40
11
12
16
17
21
25
30
49
55
62
Ω
I SAT
A DC
7.4
6.4
6.0
5.6
5.2
4.6
4.0
3.8
3.6
3.2
2.8
2.7
2.4
2.2
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.960
0.900
0.800
0.700
0.620
0.560
0.520
0.450
0.410
0.390
0.360
0.330
0.290
0.260
0.245
0.220
0.200
0.190
0.160
0.150
0.140
0.130
0.120
0.110
0.094
0.088
0.080
CURRENT
RATING
A DC
5.10
4.80
4.42
4.12
3.67
3.61
3.34
3.20
3.00
2.91
2.71
2.59
2.34
2.22
2.09
1.89
1.61
1.51
1.33
1.25
1.09
1.03
0.966
0.913
0.793
0.755
0.658
0.612
0.580
0.489
0.463
0.436
0.380
0.373
0.308
0.288
0.269
0.218
0.204
0.188
0.180
0.156
0.151
0.136
0.125
0.114
0.089
0.084
0.079
0.130
(3.30)
0.440
(11.18)
0.165
(4.19)
0.110
(2.79)
REF
0.230/0.250
(5.84/6.35)
DA
AN 01K
W
GO 25-1
0
P5
in. (mm)
0.055/0.075 (1.40/1.91) WIDE
0.050 (1.27) MIN DEEP
NOTES:
Operating Temperature Range:
-55°C to +125°C
Current Rating
is based on a 40°C temperature
rise at an ambient temperature of 85°C
Saturation Current
is the approximate value that will
reduce the initial inductance by 5%
Weight Max:
1.15 grams
Marking:
GOWANDA; P5025-xxx (dash #); tolerance
GOWANDA
P5025-101K
Epoxy-encapsulated for environmental protection and
superior strength to withstand all types of reflow
soldering
When ordering, specify
tolerance
&
termination:
Tolerance:
SMP5025-101KLF
M
= 20%,
K
= 10%
Termination: LF
= RoHS compliant tin-silver copper
over copper
Custom designs are available to meet your specific
requirements; please contact factory
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
Gowanda Electronics is an Affiliate of
(Table shows lowest standard tolerance option)
*Optional tolerances are available; contact factory
800
12 mm
24 mm
13 in.
One Magnetics Pkwy, Gowanda, NY 14070
(f ) 716-532-2702
sales@gowanda.com
REV:
ISSUE
01022020
(t) 716-532-2234
www.GowandaComponentsGroup.com
www.gowanda.com
