SPECIFICATIONS
Voltage Rating:
Current Rating:
Terminals:
Plating:
D
E
F
150 VAC RMS
1.5 Amp @25C
0.36x0.46mm Phos Bronze
contact area=selective gold
Tail=tin over Nickel
Durability:
750 cycles
Mating/Unmating:
30N Max
Retention Strength:
50N for 60S±5S
Contact Resistance:
20 milliohms Max.
Insulation Resistance: 1000 Megohms Min @500 VDC
Withstanding:
contact to contact=1000V DC/AC
Contact to screen=1500V DC/AC
Storage Temp:
-40C to +85C
Series
Positions Ports
Style
LED
Contacts
Operating Temp:
-40C to +85C
GCTJ
0X
X
TC56
LXX
X
Ganged
6, 8
2-10
Style TC56 (omitted)=no LED 4, 6, 8
modular jack
Left then right LED
(see chart)
D
LED Color Codes
Panel Grounds (X)
Blank
1,2
4
6
None
Top
Sides
Both
Code
G
Y
W
K
LED
Green
Yellow
Yellow/Green
Blank
E
Color
XX
BK=Black
RoHS compliant
Plating
PX
P0=6µ”
P1=15µ”
P2=30µ”
P3=50µ”
Options
XX
[[blank]=None
SX=Full Shield
and grounds
(see chart)
F
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
Date
11/29/’10
11/29/’10
11/29/’10 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
GCTJ-08-4-TC56LXX-8-BK-PX-XX
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Ganged modular jack
1
2
3
4
