856327_15 Overview

915 MHz SAW filter

856327
915 MHz SAW filter
Applications
ISM band wireless systems
Smart Metering systems
Remote meter reading
Wireless microphones
Wireless sensing
Wireless modules
General purpose wireless systems
CSP-8A, 2.00 x 1.50 x 0.69 mm
Product Features
Usable bandwidth 26 MHz
High attenuation
Low Loss
Excellent power handling
Single-ended operation
No impedance matching required for operation at
50Ω
Small Size: 2.00 x 1.50 x 0.69 mm
Ceramic Chip Scale Package (CSP)
Hermetically sealed
RoHS
compliant,
Pb-free
Pb
Functional Block Diagram
Gnd
4
3
Output
Input
1
2
Gnd
General Description
The 856327 is a bandpass RF SAW filter specifically
designed for the North American, Unlicensed,
Industrial, Scientific and Medical band at 915 MHz
The filter BW covers the entire available band
from 902 to 928 MHz.
The filter’s low insertion loss, 50 ohm matched ports
and compact footprint simplify system integration.
Pin Configuration - Single Ended
Pin No.
1
3
2,4
Label
Input
Output
Ground
Ordering Information
Part No.
856327
856327-EVB
Description
Product description
Evaluation board description
Standard T/R size = 10,000 units/reel
Data Sheet: Rev E 08-22-2013
© 2013 TriQuint
-
1 of 6
-
Disclaimer: Subject to change without notice
