150 MHz Bandpass Filter
Data Sheet
Typical Performance
10
0
-10
-20
-30
-40
-50
-60
-70
-80
-90
Horizontal: 3 MHz/Div
135 138 141 144 147 150 153 156 159 162 165
Vertical: 10 dB/Div
1
1.66
0
1.62
-1
1.58
-2
1.54
-3
1.5
-4
1.46
-5
1.42
-6
1.38
-7
1.34
-8
1.3
-9
1.26
Horizontal: 1 MHz/Div
145 146 147 148 149 150 151 152 153 154 155
Vertical: 1 dB/Div
Vertical: 40 nsec/Div
8 MHz Bandwidth
Part Number 855678
Parameter
Center Frequency
Insertion Loss
1 dB Lower Frequency
1 dB Upper Frequency
35 dB Lower Frequency
35 dB Upper Frequency
Amplitude Variation
Phase Ripple
Group Delay Variation
Absolute Delay
Input/Output VSWR
Substrate Material
Ambient Temperature
Specifications
Unit
Minimum
MHz
dB
MHz
MHz
MHz
MHz
dB p-p
deg p-p
nsec
µsec
-
-
°C
-
-
-
154
142.875
-
-
-
-
-
-
-
-
Typical
150
12.1
145.8
154.3
144.6
155.8
0.35
4.1
36
1.45
1.55:1
LiTaO
3
25
Maximum
-
14
146
-
-
157.125
0.75
7
150
1.8
1.8:1
-
-
Package Outline
Matching Configuration
L1 = 33 nH , L2 = 22 nH
L3 = 27 nH , L4 = 33 nH
Nominal Source/Load Impedance = 50
Ω
Package Style SMP 53
12/3/99
Sawtek Inc.
Telephone: (407) 886-8860
Fax: (407) 886-7061
