BZX85C2V7-BZX85C200
1.3 Watts Axial Leaded Zener Diodes
Features
·
Complete Voltage Range 2.7 to 200 Volts
·
Silicon planar power zener diodes.
·
For use in stabilizing and clipping circuits with high
power rating.
A
B
A
·
Standard zener voltage tolerance is
±
5%
·
Other tolerances are available upon request.
D
C
Mechanical Data
·
Case:
DO-41 Plastic Case
·
Weight:
approx. 0.25g
Dim
A
B
C
D
DO-41
Min
25.40
4.06
0.71
2.00
Max
¾
5.21
0.864
2.72
All Dimensions in mm
Maximum Ratings and Electrical Characteristics
Parameter
Zener Current see Table "Characteristics"
Maximum Forward Voltage at I
F
= 200 mA.
Power Dissipation at Ta = 25°C
Thermal Resistance Junction to Ambient Air
Junction temperature
Storage temperature range
Note:
(1) Valid provided that leads at a distance of 3/8” from case are kept at ambient temperature.
.
@ T
A
= 25°C unless otherwise specified
Symbol
V
F
P
D
R
θ
JA
T
J
T
S
Value
1.2
1.3
(1)
130
(1)
175
-55 to + 175
Unit
V
W
°C/W
°C
°C
1 of 2
ELECTRICAL CHARACTERISTICS
Rating at 25
°
C ambient temperature unless otherwise specified
Type
Number
BZX85C2V7
BZX85C3V0
BZX85C3V3
BZX85C3V6
BZX85C3V9
BZX85C4V3
BZX85C4V7
BZX85C5V1
BZX85C5V6
BZX85C6V2
BZX85C6V8
BZX85C7V5
BZX85C8V2
BZX85C9V1
BZX85C10
BZX85C11
BZX85C12
BZX85C13
BZX85C15
BZX85C16
BZX85C18
BZX85C20
BZX85C22
BZX85C24
BZX85C27
BZX85C30
BZX85C33
BZX85C36
BZX85C39
BZX85C43
BZX85C47
BZX85C51
BZX85C56
BZX85C62
BZX85C68
BZX85C75
BZX85C82
BZX85C91
BZX85C100
BZX85C110
BZX85C120
BZX85C130
BZX85C150
BZX85C160
BZX85C180
BZX85C200
Nominal Zener
Voltage
(1)
V
Z
@ I
ZT
(V)
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
I
ZT
(mA)
80
80
80
60
60
50
45
45
45
35
35
35
25
25
25
20
20
20
15
15
15
10
10
10
8.0
8.0
8.0
8.0
6.0
6.0
4.0
4.0
4.0
4.0
4.0
4.0
2.7
2.7
2.7
2.7
2.0
2.0
2.0
1.5
1.5
1.5
Maximum Zener
Impedance, f = 1kHz
Z
ZT
@ I
ZT
(Ω)
20
20
20
15
15
13
13
10
7.0
4.0
3.5
3.0
5.0
5.0
7.0
8.0
9.0
10
10
15
20
24
25
25
30
30
35
40
50
50
90
115
120
125
130
135
200
250
350
450
550
700
1000
1100
1200
1500
Z
ZK
@ I
ZK
(Ω)
400
400
400
500
500
500
500
500
400
300
300
200
200
200
200
300
350
400
500
500
500
600
600
600
750
1000
1000
1000
1000
1000
1500
1500
2000
2000
2000
2000
3000
3000
3000
4000
4500
5000
6000
6500
7000
8000
I
ZK
(mA)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Maximum Reverse Maximum DC
Leakage Current Zener Current
I
R
@ V
R
(V)
(
µ
A)
150
100
40
20
10
3.0
3.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.5
2.0
3.0
4.0
4.5
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
I
ZM
(2)
(mA)
370
340
320
290
280
250
215
200
190
170
155
140
130
120
105
97
88
79
71
66
62
56
52
47
41
36
33
30
28
26
23
21
19
16
15
14
12
10
9.4
8.6
7.8
7.0
6.4
5.8
5.2
4.7
Temp. coefficient
of Zener Voltage
α
mvz
(% /
°C)
min.
-0.08
-0.08
-0.08
-0.08
-0.07
-0.05
-0.03
-0.01
0
0.010
0.015
0.020
0.030
0.040
0.450
0.045
0.045
0.050
0.055
0.055
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.060
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
0.055
max.
-0.05
-0.05
-0.05
-0.05
-0.02
0.010
0.040
0.040
0.045
0.055
0.060
0.065
0.070
0.075
0.080
0.080
0.085
0.085
0.090
0.090
0.090
0.090
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
0.095
2 of 2
