BCR20FM-12LB_15

Description
600V - 20A - Triac Medium Power Use
File Size108KB,8 Pages
ManufacturerRenesas Electronics Corporation
Websitehttps://www.renesas.com/
Download Datasheet View All

BCR20FM-12LB_15 Overview

600V - 20A - Triac Medium Power Use

Preliminary
Datasheet
BCR20FM-12LB
600V - 20A - Triac
Medium Power Use
Features
I
T (RMS)
: 20 A
V
DRM
: 600 V
Tj: 150 °C
I
FGTI
, I
RGTI
, I
RGTIII
: 30 mA (20mA)
Note5
Insulated Type
Planar Passivation Type
Viso : 2000 V
R07DS0889EJ0100
Rev.1.00
Oct 29, 2012
Outline
RENESAS Package code: PRSS0003AG-A
(Package name: TO-220FP)
2
1. T
1
Terminal
2. T
2
Terminal
3. Gate Terminal
3
1
1
2 3
Applications
Switching mode power supply, washing machine, motor control, heater control, and other general purpose control
applications.
Maximum Ratings
Parameter
Repetitive peak off-state voltage
Note1
Non-repetitive peak off-state voltage
Note1
Parameter
RMS on-state current
Surge on-state current
I
2
t for fusion
Peak gate power dissipation
Average gate power dissipation
Peak gate voltage
Peak gate current
Junction Temperature
Storage temperature
Mass
Isolation voltage
Note6
Symbol
I
T (RMS)
I
TSM
I
2
t
P
GM
P
G (AV)
V
GM
I
GM
Tj
Tstg
Viso
Symbol
V
DRM
V
DSM
Ratings
20
200
167
5
0.5
10
2
–40 to +150
–40 to +150
1.9
2000
Unit
A
A
A
2
s
W
W
V
A
C
C
g
V
Voltage class
12
600
720
Conditions
Commercial frequency, sine full wave
360 conduction, Tc = 104C
60 Hz sinewave 1 full cycle, peak value,
non-repetitive
Value corresponding to 1 cycle of half
wave 60Hz, surge on-state current
Unit
V
V
Typical value
Ta = 25C, AC 1 minute
T
1
T
2
G terminal to case
R07DS0889EJ0100 Rev.1.00
Oct 29, 2012
Page 1 of 7
