plerow
TM
APL1015-T
PLL Synthesizer Module
Features
·
4 dBm Output Level at 1015 MHz
·
Channel Step Size : 200 kHz
·
2
nd
Harmonic : < -25 dBc
·
Spurious Level : < -70 dBc
·
Lock Time : < 10 ms
·
40 mA Current Consumption
Description
The plerow
TM
PLL synthesizer module was
designed for use in wireless and wireline
systems in a wide range of frequency from
50 MHz to 6 GHz. ASB’s PLL provides ex-
ceptionally low spurious and phase noise
performance with fast locking time and low
current consumption. All products are avail-
able in a surface-mount type package.
o
u
pl
er
C
C
o
u
pl
er
Specifications
Parameter
Frequency Range
Output Power
Supply Voltage
Current Consumption
Channel Step Size
2
nd
Harmonics
Spurious Level
Lock Time
Reference Frequency
Reference Input Level
Phase Noise (C / N)
@ 1 kHz
@ 10 kHz
@ 100 kHz
Output Impedance
Operating Temp. Range
Package Type & Size
C
mm
-40
50
25
SMT, 19.0W19.0L5.8H
80
dBc/Hz
-108
-104
Unit
MHz
dBm
V
mA
kHz
dBc
dBc
ms
MHz
dBm
3
13
200
-25
-70
10
3
4.75
Min.
Typical
1015
4
5
5
5.25
40
Website: www.asb.co.kr
E-mail: sales@asb.co.kr
Tel: (82) 42-528-7223
Fax: (82) 42-528-7222
