Fast-Acting
13
⁄
32
˝ x 1
1
⁄
2
˝ (10x38mm) Photovoltaic Midget Fuses
600 Vdc UL Listed, CSA Component Certified, 4-30A
PVM Series
8A
10 A
30 A
100
5A
Dimensions - in (mm)
15 A
20 A
AMP
RATING
1.5"
0.031
(38.1mm)
10
0.41"
Catalog Symbol: PVM
Description
A range of UL 2579 fast-acting 600Vdc Midget fuses
specifically designed to protect solar power systems in extreme
ambient temperature, high cycling and low level fault current
conditions (reverse current, multi-array fault).
TIME IN SECONDS
0.004
(10.3mm)
1
.1
Specifications
Volts: 600Vdc to UL 2579
Amps: 4 - 30A
Interrupting Rating: 50kA DC (4-30A)
1
1,000
10
100
CURRENT IN AMPS
.01
Agency Information
UL Listed 2579, Guide JFGA, File E335324, CSA Component
Certified C22.2
Power Loss (Watts)
Catalog
Number
PVM-10
PVM-15
PVM-30
I
n
= Rated current
Typical Applications
• Solar Combiner Boxes
• Inverters
• Solar Strings
Amp
Rating
10
15
30
Power Loss (Watts)
0.8 x I
n
1.0 x I
n
1.04
1.86
1.00
1.72
1.65
2.91
Recommended Fuse Blocks and Holders
• Modular CHM Series
Fuse Holders
Brochure #3185
• Open BM Series Fuse Blocks Data Sheet #1104
• In-Line Fuse Holders
Data Sheet #2127 & #2126
Catalog Numbers (amp rating)
PVM-4
PVM-5
PVM-6
PVM-7
PVM-8
PVM-9
PVM-10
PVM-12
PVM-15
PVM-20
PVM-25
PVM-30
The only controlled copy of this Data Sheet is the electronic read-only version located on the Cooper Bussmann Network Drive. All other copies of
this document are by definition uncontrolled. This bulletin is intended to clearly present comprehensive product data and provide technical informa-
tion that will help the end user with design applications. Cooper Bussmann reserves the right, without notice, to change design or construction of
any products and to discontinue or limit distribution of any products. Cooper Bussmann also reserves the right to change or update, without notice,
any technical information contained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
© 2012 Cooper Bussmann
www.cooperbussmann.com
0112 BU-SB11985
Page 1 of 1
Data Sheet 2153
