55A0822126/9CS2275 Product Details
Spec 44, Spec 55 and Spec RCW Wire and Cable
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Cable Type = Spec 55
Wire Source = United States
Cable Style = Primary
Wire Size (AWG/CM) = 12 AWG
Voltage Rating = 600 VAC
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
55A0822126/9CS2275
TE Internal Number: 479169000
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
TWO CONDUCTOR CABLE, UNSHIELDED, UNJACKETED, GENERAL... (PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Cable Type = Spec 55
Cable Style = Primary
Electrical Characteristics:
Voltage Rating (VAC) = 600
Dimensions:
Conductor Outer Diameter (mm [in]) = 2.17 [0.085]
Body Features:
Wire Size (AWG/CM) = 12 AWG
Conductor Type = SilverPlated Copper
Wire Color = Blue, White
Nominal Outside Diameter (mm [in]) = 5.64 [0.222]
Wire Diameter (mm [in]) = 2.82 [0.111]
Configuration Features:
Number of Conductors = Twisted Pair
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = M27500A12SP2U00
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Conditions for Usage:
Temperature Range (°C) = 65 – +200
Wire Size Details = 12 AWG 2.98 mm², 0.0046 in², 37 x 28 AWG
Operation/Application:
Application = Airframe Medium Weight
Packaging Features:
Wire Source = United States
Other:
Brand = Raychem
