RSF12B3321F: DescriptionFixed Resistor, Metal Oxide Film, 0.5W, 3320ohm, 250V, 1% +/-Tol, -200,200ppm/Cel,; CategoryPassive components The resistor; File Size758KB，2 Pages; ManufacturerAkahane Electronics Ind Corp; Environmental Compliance

Download Datasheet Parametric View All

RSF12B3321F Overview

Fixed Resistor, Metal Oxide Film, 0.5W, 3320ohm, 250V, 1% +/-Tol, -200,200ppm/Cel,

RSF12B3321F Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	Akahane Electronics Ind Corp
Reach Compliance Code	compliant
structure	Cylindrical
Lead diameter	0.7 mm
Lead length	28 mm
Number of terminals	2
Maximum operating temperature	155 °C
Minimum operating temperature	-55 °C
Package diameter	3 mm
Package length	9 mm
Package shape	CYLINDRICAL PACKAGE
Package form	Axial
method of packing	Bulk
Rated power dissipation(P)	0.5 W
resistance	3320 Ω
Resistor type	FIXED RESISTOR
series	RSF
technology	METAL OXIDE FILM
Temperature Coefficient	-200,200 ppm/°C
Tolerance	1%
Operating Voltage	250 V

RSF12B3321F Preview

◆

用途

－Application－

●

インバータ回路

●

スイッチング電源

●

アダプタ

●

Inverter circuit.

●

Switching power supply.

●

AC adapter.

◆

特長

－Features－

●

高信頼性の電力型抵抗器です。

●

外装は

UL94 V-0

認定品

●

自立加工、ラジアルテーピングにも

外装色

RSF :

バイオレット

/ RSMF :

グリーン

Coating color RSF : Violet / RSMF : Green

●

対応します。

RoHS

対応品

●

High reliability power type resistors.

●

“UL94 V-0” authorized coating.

●

Correspond to produce Self-stand type

●

/ Radial taping.

RoHS compliant product.

◆

構造・寸法

－Construction・Dimensions－

½ 名

Type

RSMF12B

RSMF1B

RSF12B

RSMF2B

RSF1B

RSMF3B

RSF2B

寸法

Dimensions (mm)

6.0±0.5

9.0±1.0

11.0±1.0

15.0±1.0

2.3±0.2

3.0±0.5

4.0±0.5

5.5±1.0

0.55±0.05

0.7±0.05

0.8±0.05

H (Bulk)

28±3

35±3 (Japan)

28±3 (China)

質量

Mass (mg)

210

330

580

1340(RSMF3B)

1100

リード線

Lead wire

名称

Parts Name

カッティング溝

Trimming lines

キャップ

End cap

絶縁塗装

Insulating coat

基½

Ceramic core

カラーコード

Color code

抵抗皮膜

Resistive film

◆

½名

－How to Code－

ＲＳＦ

種類

Type

標準品

Standard

小½品

RSMF Miniature

RSF

１２

定格電力

Power

Rating

0.5W

TS※

ＴＢ

包装½態

Package

Bulk

52mmTaping box

26mmTaping box

Forming

Radial Taping box

１０２

抵抗値

Resistance

Value

Ｊ

許容差

Resistance

Tolerance

±5％

±2％

±1％

G, J

4digits

3digits

※RSMF12

only

例）Ex.

0.15Ω→R15

22Ω→220

◆

負荷電力½減曲線

－Power Derating Curve－

定格電力比

PERCENT POWER RATING(％)

100

-55

155

周囲温度

AMBIENT TEMPERATURE(℃)

本カタログに記載の仕様は予告なく変更する場合がございます。ご注文及びご½用前に納入仕様書等で内容をご確認頂きます様お願い致します。

Specifications given herein are subject to change without notice. Please confirm technical specifications before you order and / or use.

http://www.akaneohm.com

marketing@akaneohm.com

◆

仕様

－Specifications－

抵抗値許容差

抵抗値範囲

½名

Type

定格電力

Power

Rating

最高½用電圧

最高過負荷電圧

Maximum Working

Maximum

Voltage

Overload Voltage

Resistance T

Tolerance

Resistance Range

F(±1%)

E24, E96

G(±2%) J(±5%)

E24

0.1Ω－47kΩ

0.1Ω－75kΩ

0.1Ω－100kΩ

0.1Ω－120kΩ

0.1Ω－75kΩ

0.1Ω－100kΩ

0.1Ω－120kΩ

RSMF12

RSMF1

RSMF2

RSMF3

RSF12

RSF1

RSF2

0.5W

250V

350V

500V

250V

350V

400V

600V

800V

400V

600V

0.1Ω－47kΩ

0.1Ω－75kΩ

0.1Ω－100kΩ

0.1Ω－120kΩ

0.1Ω－75kΩ

0.1Ω－100kΩ

0.1Ω－120kΩ

定格電圧は

定格電力´ 公称抵抗値

による計算値、又は最高½用電圧のいずれか小さい方の値とする

する。

Rated voltage =

Power Rating

NominalResistance

or Maximum Working Voltage, whichever is lower.

ever

◆

主な特性

－Characteristics－

項目

Item

½用温度範囲

Operating temp. range

抵抗温度係数

Temperature Coefficient of Resistance

耐電圧

Voltage proof

絶縁抵抗

Insulation resistance

過負荷（短時間）

Overload (Short time)

高温高湿（定常）

Damp heat (Steady state)

耐久性（70℃）

Endurance at 70℃

偶発的過負荷試験（難燃性）

Accidental overload (Flame resistance)

参考規格

Reference standards

性½

Performance or Quality Acceptance

cceptance

-55℃½+155℃

±200ppm/℃

①抵抗値変化率

Change of resistance

≦±(0.5%+0.05Ω)

≧1,000Mohm

抵抗値変化率

Change of resistance

≦±(0.75%+0.05Ω)

抵抗値変化率

Change of resistance

≦±(5.0%+0.05Ω)

抵抗値変化率

Change of resistance

≦±(5.0%+0.05Ω)

ガーゼ円筒が発炎しないこと

No flaming of gauze cup

②機械的損傷ないこと

No mechanical damage.

JIS C5201- IEC60115-1

-1,

◆

表面温度上昇 –Surface Temperature Rise

Surface

Rise－

本カタログに記載の仕様は予告なく変更する場合がございます。ご注文及びご½用前に納入仕様書等で内容をご確認頂きます様お願い致します。

Specifications given herein are subject to change without notice. Please confirm technical specifications before you order and / or use.

http://www.akaneohm.com

marketing@akaneohm.com
