D
7.8
±0.10
B
C
Pitch=4
Last HP contact
A
A
TECHNICALS FEATURES
MATERIALS
(3.4)
First HP contact
INSULATOR : Special PPS (Polyphenylene sulphide fibreglass
filled thermoplastic) UL 94-V0
Radiation resistance
No humidity absorption
Oxygen free
Note : PPS characteristics are recognized for space applications
4
5.5
±0.10
= =
12.7
CUT A-A
±0.05
0.5
5.6
4
A
FIXING HARDWARE :
Jackscrew :
Stainless steel
(4.5)
B
(A)
±0.10
(4.5)
TECHNICAL FEATURES for 30 HP CONTACTS
MATERIAL
Body
Copper alloy / Ni + Au 0.5µ
MECHANICAL
CMM Series 220 MALE
HP
contacts
number
zz
Distance between
axies
Length in
mm
Fixing
hardware
F21
Endurance
Insertion force
Extraction force
Secure overlapping
Contact replacement
In insulator
500 cycles min. up to 2500.
From 0.60 to 5N per contact
From 0.50 to 2N per contact
1.30 mm
5 cycles
3
3
A
4
8
12
16
20
24
28
32
36
40
44
48
52
56
ELECTRICAL
Intensity
Contact resistance
Maximum voltage (sea level)
Operating voltage (sea level)
10 A with AWG16
8 A with AWG18
5 A with AWG20
max. 6 mΩ
1000V (RMS)
180 V AC/500 mA
B
13
17
21
25
29
33
37
41
45
49
53
57
61
65
C
18
22
26
30
34
38
42
46
50
54
58
62
66
70
M2
(2.5)
B
±0.10
02
03
04
05
(2.5)
C
ENVIRONMENTAL
Temperature range
Vibration severity
From –60° to +260°
C
C
0.75mm, 10 g RMS 6 hours long random
with superimposed sinusoid. No intermittencies
measured when using an H.S.L.I.
(High Speed Logic Interrupt) detector with a
trip threshold of 2 ns.
100g for 6 ms
HcFc 141 bMGX (ATOCHEM) solvent
96 hrs
56 days @ 90% humidity
06
07
08
09
10
11
12
13
14
15
HP contact
30-3310
to crimp or to solder
Scale : 3:1
Solder conductor
over body
Conductor
Jacket
Shock severity
Solvent resistance
Salt spray test
Humidity test
2
2
1
1.7
6
AWG20, AWG18
or AWG16
HP contact: Crimping following cable instruction IC30HP02
Marking as referenced in the CMM catalogue pages 12 & 13
2 07/12/10
Tools recommended
HP series 30 contacts removal
Daniels AF8 hand crimp tool
HP contacts Positioner for Daniels AF8 tool
AWG16 crimp tool setting
AWG18 & 20 crimp tool setting
12368
16459
C16460
Position 5
Position 4
N.P.
Drawn
www.nicomatic.com
Mail : nicomatic@nicomatic.fr
Tel : +33 (0)4.50.36.13.85
Iss
Date
A.V.
Checked
E.M.
Approved
Item : Connector CMM220 male on cables,
zz HP contacts 30-3310, F21
General
tolerance
1
Scale
2:1
Page
1/1
Folder :
X:\Méthodes\Plans clients\Plans clients 2D\10 - CMM220\Connecteurs mâles\221E\221E00F21-00zz-3310_cl
This document and drawings, sketches, and schematic drawings are the property of
the NICOMATIC company. and no parts thereof may be reproduced and used without
the written consent of the owner. Law dated 11.03.1902
Catalogue
Reference :
221E00F21-00zz-3310
±0.2
D
A4
