BP2500D0805BT BAND PASS FILTER SPECIFICATION
Rev. A
PRODUCT FEATURES
1.
2.
3.
Surface mount band pass filter with a small size of 2.0 X 1.2 X 0.4 mm, RoHS compliant.
Provide low insertion loss, high rejection rate, and low profile thickness.
Highly stable under temperature and humidity changes.
RF CHARACTERISTICS
P/N BP2500D0805BT
Frequency range
Insertion Loss (max)
VSWR
Impedance
Specification
2400 - 2500 MHz
2.5 dB max
2.0 max
50 Ω
30 dB @
30 dB @
30 dB @
30 dB @
35 dB @
Attenuation (min.)
40 dB @
32 dB @
7 dB @
11 dB @
35 dB @
26 dB @
Operating temperature range
824 -
880 -
849 MHz
915 MHz
PHYSICAL DIMENSIONS
1545 - 1605 MHz
1565 - 1585 MHz
1710 - 1785 MHz
1850 - 1910 MHz
1920 - 1980 MHz
3168 -
4752 MHz
L
W
T
A
B
C
D
E
F
Symbol
Dimension
(mm)
2.00 ± 0.15
1.25 ± 0.10
0.45 ± 0.10
0.95 ± 0.10
0.275 ± 0.10
0.25 ± 0.10
0.60 ± 0.10
0.175 ± 0.10
0.15 ± 0.10
3300 - 3800 MHz
4800 - 4967 MHz
5150 - 6000 MHz
23 dB @ 7200 - 7450 MHz
-40°C to +85°C
TERMINAL CONFIGURATION
PIN
P1
P2
Definition
INPUT
GND
OUTPUT
P2
P1
P3
P3
Frontier Electronics Corp.
®
http://www.frontierusa.com
Page
1
of
2
667 E. Cochran St., Simi Valley, CA 93065
Phone: 1-805-522-9998, Fax: 1-805-522-9989
BP2500D0805BT BAND PASS FILTER SPECIFICATION
Rev. A
PCB DESIGN/LAYOUT CONSIDERATION
Figure
Symbol
L1
W1
W2
D1
S1
Dimension (mm)
0.60 ± 0.10
0.70 ± 0.05
2.25 ± 0.10
0.20 ± 0.05
0.25 ± 0.05
Note:
- Design trace width to be 50Ω impedance.
Typical RF Performance
Frontier Electronics Corp.
®
http://www.frontierusa.com
Page
2
of
2
667 E. Cochran St., Simi Valley, CA 93065
Phone: 1-805-522-9998, Fax: 1-805-522-9989
