SPS-9330VW-CXX1RG
FEATURES
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
SMPTE 297-2006 Compatible
Speed from 50 Mbps to 3Gbps
Power Budger > 15 dB
Support Video Pathological Patterns for SD-SDI,
HD-SDI and 3G-SDI
Single CWDM Transmitter: 1270 nm to 1610 nm
Single Receiver with Simplex LC
Based on Industry Standard SFP
SFF-8472 Digital Diagnostic Function
TTL Laser Disable Input
TTL TX_Fault Output
TTL RX_LOS Output
Single +3.3 V Power Supply
RoHS-6 Compliant
0 to 70
o
C Operation
Hot Pluggable
Class 1 Laser International Safety Standard IEC-60825
Compliant
SPS-9330VW-CXX1RG
1
***********************************************************************************************************************************************************************
(RoHS Compliant)
DESCRIPTION
The SPS-9330VW-CXX1RG is a optical single mode
transmitter/receiver module designed to transmit/receive
optical serial digital signals as defined in SMPTE 297-2006.
It supports from 50 Mbps to 3 Gbps and is specifically
designed for transmitted the SMPTE 259M, SMPTE 344M,
SMPTE 292M and SMPTE 424M SDI pathological
patterns. It is with the SFP 20-pin connector to allow hot
plug capability. Digital diagnostic functions are available
via an I
2
C. This module is designed for single mode fiber
and operates at a nominal wavelength of CWDM
wavelength. There are eighteen center wavelengths
available from 1270 nm to 1610 nm, with each step 20 nm.
A guaranteed minimum optical link budget of 15 dB is
offered. The transmitter section uses a multiple quantum
well CWDM DFB laser and is a class 1 laser compliant
according to International Safety Standard IEC-60825. The
receiver section uses an integrated InGaAs detector
preamplifier (IDP) mounted in an optical header and a
limiting post-amplifier IC.
CWDM /
3 Gb/s
Medium Power
Optical SM Digital Diagnostic Transmitter/Receiver
**********************************************************************************************************************************************************************
APPLICATIONS
l
SMPTE 297-2006 Compliant Electrical-to-Optical
Interfaces
l
High-density Video Routers
LASER SAFETY
This single mode transceiver is a Class 1 laser product. It
complies with IEC-60825 and FDA 21 CFR 1040.10 and
1040.11. The transceiver must be operated within the
specified temperature and voltage limits. The optical ports
of the module shall be terminated with an optical connector
or with a dust plug.
ORDER INFORMATION
P/No.
Type
Bit Rate
(Mb/s)
TX
λ
(nm)
XX*
Power
(dBm)
0 to -5
λ
(nm)
RX
Sen.
(dBm)
Package
Temp
(
o
C)
RoHS
Compliant
Yes
SPS-9330VW-CXX1RG
1-TX+1-RX
50 to 3000
1260/1620 0 to -20 LC SFP with DMI 0 to 70
Min.
(nm)
1444.5
1464.5
1484.5
1504.5
1524.5
1544.5
1564.5
1584.5
1604.5
Typ.
(nm)
1450
1470
1490
1510
1530
1550
1570
1590
1610
Max.
(nm)
1457.5
1477.5
1497.5
1517.5
1537.5
1557.5
1577.5
1597.5
1617.5
XX*
: CWDM Wavelength (0 to 70 C)
Central
Wavelength
-C270
-C290
-C310
-C330
-C350
-C370
-C390
-C410
-C430
Min.
(nm)
1264.5
1284.5
1304.5
1324.5
1344.5
1364.5
1384.5
1404.5
1424.5
Typ.
(nm)
1270
1290
1310
1330
1350
1370
1390
1410
1430
Max.
(nm)
1277.5
1297.5
1317.5
1337.5
1357.5
1377.5
1397.5
1417.5
1437.5
Clasp Color
Central
Code
Wavelength
Light Purple
-C450
Sky Blue
-C470
Yellow Green
-C490
Yellow Ocher
-C510
Pink
-C530
Beige
-C550
White
-C570
Silver
-C590
Black
-C610
Clasp Color
Code
Yellow Orange
Gray
Violet
Blue
Green
Yellow
Orange
Red
Brown
o
CWDM*: 18 Wavelengths from 1270 nm to 1610 nm, each step 20 nm.
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
E-mail: sales@optoway.com.tw
Fax: 886-3-5979737
http: // www.optoway.com.tw
8/1/2009 V2.0
Optoway
ABSOLUTE MAXIMUM RATINGS
Absolute Maximum Ratings
Parameter
Storage Temperature
Operating Case Temperature
Power Supply Voltage
ESD Tolerance on all pins
Relative Humidity
Symbol
Tstg
Tc
Vcc
---
Min
-40
0
0
5
Max
85
70
4
1
95
SPS-9330VW-CXX1RG
2
***********************************************************************************************************************************************************************
Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Units
o
C
o
C
V
KV HBM
% RH
Notes
non-condensing
Recommended Operating Conditions
Parameter
Symbol
Power Supply Voltage
Vcc
Operating Case Temperature
Tc
Baud Rate
Power Supply Current
Icc
Min
3.13
0
50
Typ
3.3
200
Max
3.47
70
3000
300
Units / Notes
V
o
C
Mb/s
mA
Transmitter Specifications (0
o
C < Tc < 70
o
C, 3.13V < Vcc < 3.47V)
Parameter
Optical
Optical Transmit Power
Output Center Wavelength
Output Spectrum Width
Side Mode Suppression Ratio
Extinction Ratio
Relative Intensity Noise
Symbol
Po
λ
∆λ
SMSR
ER
RIN
Min
-5
λc
–5.5
---
30
5
Typ
Max
0
λc
+7.5
1
7.5
-120
135
270
800
1.5
200
0
2.0
0
2.5
2.5
0
1200
0.8
Vcc+0.3
0.5
Vcc+0.3
Vcc+0.3
0.5
Units
dBm
nm
nm
dB
dB
dB/Hz
ps
ps
ps
ns
mVp-p
V
V
V
V
V
V
Notes
1
2
-20 dB width
λc
Optical Rise Time / Fall Time
tr / tf
3, SMPTE 424M
3, SMPTE 292M
3, SMPTE 344M
3, SMPTE 259M
AC coupled input
TX Output Enabled
TX Ouput Disabled
Electrical
Differential Input Voltage
Disable Input Voltage -- Low
Disable Input Voltage -- High
Output TX_Fault -- Low
Output TX_Fault -- High
SCL, SDA
1.
2.
3.
V
IH
- V
IL
V
TDIS,L
V
TDIS,H
V
OL
V
OH
V
OH
V
OL
Output power is power coupled into a 9/125
µm
single mode fiber.
ITU-T G.694.2 CWDM wavelength from 1270 nm to 1610 nm, each step 20 nm.
20% to 80%, unfiltered.
Receiver Specifications (0
o
C < Tc < 70
o
C, 3.13V < Vcc < 3.47V)
Parameter
Optical
Wavelength of Operation
Sensitivity for SMPTE 424M
2.97 Gb/s
Sensitivity for SMPTE 292M
1.485 Gb/s
Signal Detect -- Asserted
Signal Detect -- Deasserted
Symbol
Min
1260
0
0
0
0
---
-29
Typ
---
---
---
---
---
Max
1620
-18
-20
-20
-21
-20
---
Units
nm
dBm
dBm
dBm
dBm
dBm
dBm
Notes
Sen
Sen
Pa
Pd
Pathological
PRBS 2
23
-1, BER=1E-12
Pathological
PRBS 2
23
-1, BER=1E-12
Transition: low to high
Transition: high to low
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
8/1/2009 V2.0
Optoway
Signal detect -- Hysteresis
Optical Return Loss
Electrical
CML Output (Differential)
1
-27
550
660
850
135
270
800
1.5
0.5
Vcc+0.3
Vcc+0.3
0.5
6
SPS-9330VW-CXX1RG
dB
dB
mVp-p
ps
ps
ps
ns
V
V
V
V
AC coupled output
4, SMPTE 424M
4, SMPTE 292M
4, SMPTE 344M
4, SMPTE 259M
3
***********************************************************************************************************************************************************************
Optical Rise Time / Fall Time
tr / tf
Output LOS Voltage -- Low
Output LOS Voltage -- High
SCL, SDA
4.
20% to 80%, unfiltered.
V
OL
V
OH
V
OH
V
OL
0
2.5
2.5
0
I
OL
=-1.6mA, 1 TTL unit load
I
OH
=40µA, 1 TTL unit load
MODULE DEFINITION
Module Definition
4
PIN 5
SCL
PIN 6
SDA
Interpretation by Host
Serial module definition protocol
Module Definition 4 specifies a serial definition protocol. For this definition, upon power up, SCL and SDA appear as no connector
(NC). When the host system detects this condition, it activates the serial protocol. The protocol uses the 2-wire serial CMOS E
2
PROM
protocol of the ATMEL AT24C01A/02/04 family of components.
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
8/1/2009 V2.0
Optoway
CONNECTION DIAGRAM
SPS-9330VW-CXX1RG
4
***********************************************************************************************************************************************************************
PIN
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Name
Vee
TX_Fault
NC
Vee
SCL
SDA
Vee
RX_LOS
NC
NC
Vee
RX-
RX+
Vee
Vcc RX
Vcc TX
Vee
TX+
TX-
TX_DIS
Function
Signal Ground
Transmitter Fault Indicator (Active high,
open-drain)
No Connection
Signal Ground
Serial I
2
C Clock
Serial I
2
C Data
Signal Ground
Receiver Loss of Signal Indicator (Active
high, open-drain)
No Connection
No Connection
Signal Ground
Negative Differential Output
Positive Differential Output
Signal Ground
Power Supply
Power Supply
Signal Ground
Positive Transmitter Data In
Negative Transmitter Data In
Transmitter Disable
Notes
+3.3V±5%
+3.3V±5%
AC coupled differential lines with 100 ohm
differential termination inside the module
Internal 4.7 kΩ pull-up. The bias current and
modulation current are turned off if TX1_DIS =
HIGH.
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
8/1/2009 V2.0
Optoway
RECOMMENDED CIRCUIT SCHEMATIC
VCC 3.3V
1
4.7K
TX_FAULT
VCC 3.3V
5
4.7K
I2C CLK
I2C DATA
RX_LOS
4.7K
4.7K
6
7
8
9
10
2
3
4
Vee
TX_FAULT
NC
Vee
SCL
SDA
Vee
RX_LOS
NC
NC
TX_DIS
TX -
TX +
Vee
Vcc_TX
Vcc_RX
Vee
RX +
RX -
Vee
20
19
18
17
16
15
14
13
12
11
100nF
100nF
TX_DIS
SPS-9330VW-CXX1RG
5
***********************************************************************************************************************************************************************
TD -
100Ω Differential
TD +
10uF
1uH
1uH
10uF 100nF
10uF
VCC 3.3V
Re-Clocker
RD +
100Ω Differential
Re-Clocker
RD -
VCC 3.3V
1. Consult the Chipset manufacturer’s applications information for biasing required for TX outputs. Some chipset outputs
are internally biased and may not need external bias resistor.
PACKAGE DIAGRAM (
Units in mm)
***********************************************************************************************************************************************************************
OPTOWAY TECHNOLOGY INC.
No.38, Kuang Fu S. Road, Hu Kou, Hsin Chu Industrial Park, Hsin Chu, Taiwan 303
Tel: 886-3-5979798
Fax: 886-3-5979737
E-mail: sales@optoway.com.tw http: // www.optoway.com.tw
8/1/2009 V2.0
