Crystal oscillator
Product Number (please contact us)
Q33550xx0xxxx00
CRYSTAL OSCILLATOR (SPXO)
OUTPUT : CMOS
SG - 550
series
Frequency
range
Supply
voltage
Current
consumption
Function
External
dimensions
2 MHz to 48 MHz
1.8 V Typ. / 2.5 V Typ. / 3.3 V Typ.
1.5 mA Typ.
(SEF: 1.8 V No load condition 48 MHz)
:
Standby(
ST
)
:
5.0 × 3.2 × 1.2 mm
:
:
:
Actual size
Specifications (characteristics)
Item
Output frequency range
Supply voltage
Storage temperature
Operating temperature
Frequency tolerance
Symbol
f
0
V
CC
T_stg
T_use
f_tol
Specifications
SG-550SDF
SG-550SCF
2.000 MHz to 48.000 MHz
1.8 V Typ.
2.5 V Typ.
3.3 V Typ.
1.6 V to 2.2 V
2.2 V to 3.0 V
2.7 V to 3.6 V
-40
C
to +125
C
-40
C
to +85
C
B:
50
10
-6
,C:
100
10
-6
M:
100
10
-6
L:
50
× 10
-6
1.5 mA Max.
1.5 mA Max.
1.5 mA Max.
1.5 mA Max.
1.5 mA Max.
2.0 mA Max.
1.5 mA Max.
2.0 mA Max.
2.5 mA Max.
2.0 mA Max.
2.0 mA Max.
2.5 mA Max.
2.0 mA Max.
2.5 mA Max.
3.5 mA Max.
3.0 mA Max.
3.5 mA Max.
4.5 mA Max.
0.7
A
Max.
1.5
A
Max.
2.0
A
Max.
45 % to 55 %
45 % to 55 %
40 % to 60 %
40 % to 60 %
90 % V
CC
Min.
10 % V
CC
Max.
15 pF Max.
80 % V
CC
Min.
20 % V
CC
Max.
4 ns Max.
10 ms Max.
SG-550SEF
5
10
-6
/ year Max.
Conditions / Remarks
Please contact us about available frequencies.
Storage as single product.
-20
C
to +70
C
-40
C
to +85
C
-40
C
to +85
C
V
CC
5
%
No load condition, 2 MHzf
0
4 MHz
No load condition, 4 MHz<f
0
8 MHz
No load condition, 8 MHz<f
0
16
MHz
No load condition, 16 MHz<f
0
25
MHz
No load condition, 25 MHz<f
0
33
MHz
No load condition, 33 MHz<f
0
48
MHz
ST
=GND
2 MHz≤f
0
16
MHz
50 % V
CC
level
16 MHz<f
0
40
MHz
L_CMOS
15 pF
40 MHz<f
0
48
MHz
I
OH
=-3 mA
I
OL
= 3 mA
ST
terminal
Current consumption
I
CC
Stand-by current
Symmetry
Output voltage
Output load condition(CMOS)
Input voltage
Rise time / Fall time
Start-up time
Frequency aging
I_std
SYM
V
OH
V
OL
L_CMOS
V
IH
V
IL
t
r
/ t
f
t
sta
f_aging
20 % V
CC
to 80 % V
CC
level, L_CMOS=15 pF
t=0 at 90 % V
CC
+25
C,
First year,
V
CC
=1.8 V, 2.5 V, 3.3 V
Product Name
(Standard form)
SG-550 S E F 22.000000MHz B
①
②③
④
⑤
①Model
②Function
(S:Standby)
③Supply
voltage
④Frequency
⑤Frequency
tolerance
(Unit:mm)
③Supply
voltage
E
1.8 V Typ.
D
2.5 V Typ.
C
3.3 V Typ.
⑤Frequency
tolerance
-6
B
±50 × 10 / -20 to +70°C
-6
C
±100 × 10 / -20 to +70°C
-6
L
±50 × 10 / -40 to +85°C
-6
M
±100 × 10 / -40 to +85°C
(Unit:mm)
External dimensions
5.0
0.2
Footprint (Recommended)
#4
#3
Pin map
Pin
Connection
1
ST
2
GND
3
OUT
4
V
CC
1.6
3.2
0.2
2.8
E 22.00B
7FC81A
#1
#2
1.2 Max.
0.1
1.0
2.54
0min.
(0.35)
2.5
(0.35)
2.2
Note.
ST
pin
ST
pin = HIGH or "open" : Specified frequency output.
ST
pin = LOW : oscillation stops. High-z
The metal case inside of the molding compound may be exposed
on the top or bottom of this product.
This purely cosmetic and does not have any effect on quality,
reliability or electrical specs.
2.54
To maintain stable operation, provide a 0.01uF to
0.1uF by-pass capacitor at a location as near as
possible to the power source terminal of the crystal
product (between Vcc - GND).
1.5
