Oven Controlled Crystal Oscillator
OX-170
OX-170
Features
•
•
•
•
•
Reflow Process Compatible
AT-Cut and SC-Cut Crystal Options
Low Profile Compact Package
Previous Model: C4600
Frequency Range: 5 MHZ to 80 MHZ
•
•
•
•
•
Applications
Base Stations
Test Equipment
Synthesizers
Military Communication Equipment
Digital Switching
Performance Specifications
Frequency Stabilities
1
(AT-Cut Crystal-Standard)
Parameter
vs. operating temperature range
(referenced to +25°C)
Min
-30
-80
-100
-200
-300
-5
-5
-2
-500
-250
Typical
Max
+30
+80
+100
+200
+300
+5
+5
+2
+500
+250
5
Unit
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Condition
0 to +70°C
-20 to +70°C
-40 to +70°C
-40 to +85°C
at time of shipment, nominal EFC
V
S
±5% static
Load ±5% static
after 30 days of operation
after 30 days of operation
after 30 days of operation
to ±100ppb of final frequency (1 hour
reading) @ +25°C
0 to +70°C
-20 to +70°C
-40 to +70°C
-40 to +85°C
at time of shipment, nominal EFC
V
S
±5% static
Load ±5% static
after 30 days of operation
after 30 days of operation
after 30 days of operation
to ±10ppb of final frequency (1 hour read-
ing) @ +25°C
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging/day
vs. aging/1st year
vs. aging/year (following years)
Warm-up time
Frequency Stabilities
1
(SC-Cut Crystal-Option)
vs. operating temperature range
(referenced to +25°C)
-10
-15
-20
-30
-0.1
-5
-5
-1
-100
-50
+10
+15
+20
+30
+0.1
+5
+5
+1
+100
+50
5
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
ppb
minutes
Initial tolerance
vs. supply voltage change
vs. load change
vs. aging/day
vs. aging/1st year
vs. aging/year (following years)
Warm-up time
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Performance Specifications
Supply Voltage (Vs)
Parameter
Supply Voltage
Supply Voltage
Supply Voltage
Power Consumption
Min
3.135
4.75
11.4
Typical
3.3
5.0
12.0
Max
3.465
5.25
12.6
3.5
1.0
Unit
VDC
VDC
VDC
Watts
Watts
Condition
during warm-up
steady state @ +25°C
RF Output
Signal [Standard]
Load
Signal Level (Vol)
Signal Level (Voh)
Duty Cycle
Signal
Load
Output Power
Harmonics
Tuning Range
Tuning Range
Linearity
Tuning Slope
Control Voltage Range
0.0
0.0
2.75
3.92
4.9
1.4
2.0
2.8
4.0
5.0
Positive
2.8
4.0
2.85
4.08
5.1
-90
-120
-140
-145
-150
-75
-105
-130
-140
-150
25
VDC
VDC
VDC
VDC
VDC
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
dBc/Hz
g
1 Hz
10 Hz
100 Hz
1 kHz
10 kHz
1 Hz
10 Hz
100 Hz
1 kHz
10 kHz
with Vs=3.3V
with Vs=5V & 12V
with Vs=3.3V
with Vs=5V
with Vs=12V
±6.0
±0.75
+2.0
+5.0
50
+5.0
+8.0
+8.0
+11.0
-30
Fixed OCXO; No adjust
±12.0
±2.0
10
ppm
ppm
%
with AT cut crystal
with SC cut crystal
2.4
3.5
45
55
Sinewave
Ohms
dBm
dBm
dBc
with Vs=3.3V and 50 Ohm load
with Vs=5V & 12V and 50 Ohm load
50 Ohm load
15
0.4
0.5
HCMOS
pF
VDC
VDC
VDC
VDC
%
with Vs=3.3V and 15 pF Load
with Vs=5V & 12V and 15 pF Load
with Vs=3.3V and 15 pF Load
with Vs=5V & 12V and 15 pF Load
@ (Voh-Vol)/2
Frequency Tuning (EFC)
Reference Voltage Output (VRef)
Reference Voltage
Additional Parameters
@ 10MHz
with SC cut
Phase Noise
3
Phase Noise
3
@ 10MHz
with AT cut
Weight
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Performance Specifications
Absolute Maximum Ratings
Parameter
Supply Voltage (Vs)
Output Load
Operable Temperature Range
Storage Temperature Range
-55
-55
Min
Typical
Max
6.5
15
50
+85
+125
Unit
V
V
pF
°C
°C
Condition
with Vs=3.3V & 5V
with Vs=12V
Outline Drawing / Enclosure
Dimensions in mm
Type A
Code
0
1
2
3
Height “H”
12.2
13.5
15.2
18.2
Pin Length “L” Min
4.5
4.5
4.5
4.5
Pin Connections
1
2
3
4
5
Electronic Frequency Control Input (EFC)
No Connect / Reference Voltage Output
Supply Voltage Input (Vs)
RF Output
Ground (Case)
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
Ordering Information
OX - 170 0 - D A E - 258 0 - 10M0000000
Product Family
OX: OCXO
Package
25x38mm
Height
0: A12.2 mm
1: A13.5 mm
2: A15.2 mm
3: A18.2 mm
Stability Code
108: ±10ppb
158: ±15ppb
208: ±20ppb
258: ±25ppb
308: ±30ppb
508: ±50ppb
107: ±100ppb
207: ±200ppb
Temperature Range
D: -40°C to +70°C
E: -40°C to +85°C
J: -20°C to +70°C
T: 0°C to +70°C
Frequency
Frequency Control
0: No Tuning
1: ±0.75 to ±2.0ppm (SC)
2: ±6.0 to ±12.0ppm (AT)
Supply Voltage
B: +12V
D: +5V
E: +3.3V
RF Output Code
A: HCMOS
E: Sinewave
Notes:
1. Contact factory for improved stabilities or additional product options. Not all options and codes are available at all
frequencies.
2. Unless other stated all values are valid after warm-up time and refer to typical conditions for supply voltage, frequency
control voltage, load, temperature (25°C).
3. Phase noise degrades with increasing output frequency.
4. Subject to technical modification.
5. Contact factory for availability.
For Additional Information, Please Contact
Vectron International
267 Lowell Road, Suite 102
Hudson, NH 03051
Tel: 1.888.328.7661
Fax: 1.888.329.8328
USA:
Vectron International
Landstrasse, D-74924
Neckarbischofsheim, Germany
Tel: +49 (0) 3328.4784.17
Fax: +49 (0) 3328.4784.30
Europe:
Vectron International
68 Yin Cheng Road(C), 22nd Floor
One LuJiaZui
Pudong, Shanghai 200120, China
Tel: +86 21 6194 6886
Fax: +86 21 6194 6699
Asia:
Disclaimer
Vectron International reserves the right to make changes to the product(s) and or information contained herein without notice. No liability is assumed as a result of their use or application.
No rights under any patent accompany the sale of any such product(s) or information.
Rev: 2-18-14 jar
Vectron International • 267 Lowell Road, Hudson, NH 03051 • Tel: 1-88-VECTRON-1 • http://www.vectron.com
