REAL TIME CLOCK MODULE (SPI-Bus)
RTC - 4574SA
/
JE
/
NB
Built
in frequency adjusted 32.768 kHz crystal unit.
Interface
Type
:
3-wire serial interface
Operating
voltage range
:
1.6Vto5.5V
Wide
Timekeeper voltage range
:
1.6Vto5.5V
Low
backup current
:
0.5A/3V(Typ.)
32.768
kHz frequency output function
:
C-MOS output With Control Pin
The
various functions include full calendar, alarm, timer.
Actual size
RTC-4574SA
RTC-4574JE
RTC-4574NB
Block diagram
32.768 kHz
CONTROL LINE
Overview
32.768
kHz frequency output function
• FOUT pin output (C-MOS output ), CL=30 pF
• Output frequency selectable from1/30Hz to 32.768kHz
(32 Values)
OSC
DIVIDER
CLOCK and
CALENDAR
FOUT
FCON
/ TIRQ
/ AIRQ
DATA
CLK
CE 1
CE 0
Timer
function
OUTPUT
CONTROLLER
INTERRUPTS
CONTROLLER
ALARM
REGISTER
CONTROL
REGISTER
INTERFACE
CIRCUIT
SHIFT REGISTER
TIMER
REGISTER
• Timer function can be set up between 1/4096 second and
255 minutes.
• It is recorded automatically to TF-bit at the time of event
occurrence, and it’s possible to output with /TIRQ pin output
(open-drain output).
• Selectable one time mode or repeat mode.
Alarm
function
BUS
• Alarm function can be set to any combination of day of week,
hour, or minute.
• It is recorded automatically to AF-bit at the time of event
occurrence, and it’s possible to output with /AIRQ pin
output (open-drain output).
Functions are compatible with RX-4574LC.
Terminal connection/External dimensions
RTC4574SA
1.27
(Unit:mm)
RTC4574NB
20.
19.
7.0
0.3
RTC4574JE
14.
10.1
0.2
2.
13.
12.
11.
CE1
DATA
CLK
/TIRQ
/AIRQ
CE0
3.
4.
5.
6.
10.
7.
8.
9.
10.
FOUT
CE0
/AIRQ
/TIRQ
CLK
DATA
CE1
FCON
GND
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
FCON
N.C.
CE1
DATA
CLK
/TIRQ
/AIRQ
CE0
FOUT
V
DD
0.5
1.
2.
3.
4.
5.
6.
7.
GND
FOUT
N.C.
N.C.
FCON
0.65
1.
V
DD
N.C.
1.
GND
6.3
Max.
22.
21.
20.
19.
18.
17.
4.8
1.3
0.1
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
N.C.
18.
17.
16.
15.
5.0
N.C.
3.2
0.1
5.4
14.
1.5
Max.
13.
16.
15.
14.
13.
12.
N.C.
V
DD
7.4
0.2
9.
8.
12.
6.0
0.2
11.
5.0
0.2
SOP14
pin
VSOJ20
pin
SON22
pin
The metal case inside of the molding compound may be exposed on the top or bottom of this product. This purely cosmetic and does not have any effect on quality, reliability or electrical specs.
Specifications (characteristics)
Recommended Operating Conditions
Item
Power voltage
Clock voltage
Operating
temperature
Symbol
V
DD
V
CLK
T
OPR
Conditions
-
-
-
Min.
1.6
1.6
-40
Typ.
3.0
3.0
+25
Max.
5.5
5.5
+85
Unit
V
V
°C
I
BK
Item
Symbol
Refer
to application manual for details.
Current consumption characteristics
Conditions
V
DD
=5V
V
DD
=3V
V
DD
=5V
V
DD
=3V
Min.
-
T
a
=-40Cto+85C
Typ.
1.0
Max.
2.0
Unit
CE0,CE1=GND
FOUT;output OFF
(Hi-z)
µA
-
0.5
1.0
Frequency characteristics
Item
Frequency
tolerance
Oscillation
start-up time
Symbol
f/f
Conditions
T
a
=+25°C
V
DD
=3.0V
T
a
=+25°C
V
DD
=1.6V
Rating
B:
523
3Max.
Unit
10
6
s
Current
Consumption
CE0=GND
CE1=V
DD
I
32k
FOUT;
32.768kHzoutput ON
CL=30pF
-
8.0
20.0
µA
t
STA
-
5.0
12.0
Please ask for tighter tolerance.(Equivalent
to 1 minute of monthly deviation)
