SHEET 1 OF 1
7.62
.05
[.300
.002
in]
3
4
5
[.037
.002
in]
.95
.05
3.00
5.08
.05
[.200
.002
in]
[.118 in]
7.40
[.291 in]
1
PC MOUNTING
3
4
5
2
2.54
[.100 in]
3
4
5
7.40
[.291 in]
1
2
1
2
2.50
[.098 in]
3.65
[.144 in]
CIRCUIT: SPST
5.00
[.197 in]
NOTES
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
0.4
X.XX=
0.25
3. TERMINAL NUMBERS FOR REF. ONLY.
4. OPERATING FORCE: 160
50gf
5. OPERATING LIFE: 1,000,000 CYCLES
6. TRAVEL: 0.5
0.15mm
7. CONTACT RATING: 12VDC @ 50mA
8. CONTACT RESISTANCE: 100m
W
MAX
9. INSULATION RESISTANCE: 100M
W
MIN @ 100VDC.
10. CONTACT MATERIAL: SILVER
11. OPERATING TEMPERATURE: -40
C TO 85
C
12. PACKAGING: TUBE 60 PCS. PER
13. DENOTES CRITICAL PARAMETER
14. 2002/95/EC (ROHS) COMPLIANT
4.70
[.185 in]
2.70
.50
[.106
.020
in]
5
2.10
.50
[.083
.020
in]
2
4
4.20
.50
[.165
.020
in]
.30
[.012 in]
7.62
.50
[.300
.020
in]
9.00
.50
[.354
.020
in]
.50
[.020 in]
2.54
[.100 in]
5.08
[.200 in]
.50
[.020 in]
A
REV
21192
PCR NO
New Release
DESCRIPTION
8/06/13
DATE
rc
BY
TITLE
SCALE
TL6105AF160QP
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
8/1/2013
rc
DR
T350501
DWG
REV
A
