SHEET 1 OF 1
3
5.80
[.228 in]
4
1.00
[.039 in]
4.00
[.157 in]
1
12.00
[.472 in]
2
7.40
[.291 in]
5.00
[.197 in]
4.00
[.157 in]
3
4
7.40
[.291 in]
3
4
1
2
1
2
3.00
[.118 in]
CIRCUIT: SPST
NOTES
1. ALL DIMENSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
0.4
X.XX=
0.25
3. TERMINAL NUMBERS FOR REF. ONLY.
4. OPERATING FORCE: 130
50gf
5. OPERATING LIFE: 1,000,000 CYCLES
6. TRAVEL: 0.5
0.15mm
7. CONTACT RATING: 12VDC @ 50mA
8. CONTACT RESISTANCE: 100m
W
MAX
9. INSULATION RESISTANCE: 100M
W
MIN @ 100VDC.
10. CONTACT MATERIAL: SILVER
11. OPERATING TEMPERATURE: -40
C TO 85
C
12. PACKAGING: TAPE & REEL, 700 PCS. PER REEL
13. DENOTES CRITICAL PARAMETER
14. 2002/95/EC (ROHS) COMPLIANT
2.60
[.102 in]
5.20
[.205 in]
2.50
[.098 in]
10.00
.50
[.394
.020
in]
3.65
[.144 in]
A
REV
21188
PCR NO
New Release
DESCRIPTION
8/01/13
DATE
rc
BY
TITLE
SCALE
TL6120BF130QG
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
6/24/2013
rc
DR
T351501
DWG
