T223005 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > T223005

Preview

T223005: DescriptionAll Dimension In MM; File Size71KB，1 Pages; ManufacturerE-Switch; Websitehttp://www.e-switch.com

Download Datasheet View All

T223005 Overview

All Dimension In MM

Preview

Download Datasheet

View All

SHEET 1 OF 1

5.08

[.200 in]

.76

[.030 in]

5.08

[REF]

[.200 in]

ISOMETRIC

2.54

[.100 in]

P.C. MOUNTING

5.08

[.200 in]

1.09

KEYWAY

9.14

[.360 in]

2.54

[.100 in]

SWITCH FUNCTION

POS. 1

POS. 2

POS. 3

[.043 in]

4.60

[.181 in]

5.2

[.20 in]

2.54

[.100 in]

POS. 2

POS. 1

2-3, 5-6

OFF

OPEN

2-1, 5-4

.25

[.010 in]

12.30

[.484 in]

POS. 3

.58

[.023 in]

4.95

3.30

[.130 in]

4.01

[.158 in]

5.08

[.200 in]

5.59

[.220 in]

[.195 in]

PANEL MOUNTING

CIRCUIT: DPDT

RATING

NOTE:

1. ALL DIMENSIONS IN MM [INCH]

2. GENERAL TOLERANCE: X.X=±0.4

X.XX=±0.25

3. TERMINAL NUMBERS FOR REF ONLY

4. PLATING MATERIAL: GOLD

5. RATING: 0.4 VA max. @ 20 V (AC or DC) max.

6. ELECTRIC LIFE: 30,000 MAKE-AND-BREAK CYCLES

AT FULL LOAD.

7. INSULATION RESISTANCE: 1,000 MEGA-OHM MIN.

8. DIELECTRIC STRENGTH: 1,000 V RMS @SEA LEVEL.

9. OPERATING TEMP.: -30°C to 85°C

10.

DENOTES CRITICAL PARAMETER.

E-LOGO ON

OPPOSITE SIDE

.41

[.016 in]

.51

[.020 in]

2.54

[.100 in]

8.13

[.320 in]

EPOXY

SEAL

.76

[.030 in]

2.54

[.100 in]

REV

18159

PCR NO

RELEASED FOR PRODUCTION

DESCRIPTION

7/1/08

DATE

BLR

TITLE

200MDP3T4B4M6RE

DATE

THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY

TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED

SCALE

2:1

DWG

REV

7/1/2008

BLR

T223005
