<HAR> Hook-up Wire
H05V-K, UL Style 1007 + 1569, UL/CSA
H07V-K, UL Style 1015 + 1063, UL (MTW)/ CSA
This hook-up wire has international approvals to satisfy the requirements of
both North America and Europe. It passes <HAR> H05V-K, <HAR>
H07V-K, UL AWM, UL MTW (16 AWG and larger), CSA TEW and CE.
Recommended Applications:
Panel and machine wiring for domestic and export usage. Electronic
equipment, Medical Equipment, and Wire bundling
Application Advantage:
• One inventory vs. two for domestic and
export consumption
• 13 color code options
• UL MTW for 16 AWG and larger
• Available in large cardboard barrels for
easy pull (16 AWG MTW and larger
only) Call your sales representative for
P/N and availability
Color Code:
00=
01=
02=
03=
04=
05=
06=
Green/Yellow
Black
Blue
Brown
Red
White
Gray
07= Violet
08= Pink
09= Orange
10= Yellow **
11= Green **
14= Dark Blue
<HAR> Hook-up Wire Construction:
Finely stranded tinned copper conductors; PVC insulation
Cable Attributes, See Page 653
Oil Resistance:
OR-02
Motion Type:
FL-02
Flame
Resistance:
FR-02
Mechanical
Properties:
MP-01
Complete the installation with:
SKINTOP
®
Strain Relief:
Page 486
SKINTOP
®
DIX
Page 524
EPIC
®
Connectors:
Page 251
FLEXIMARK
®
Marking:
Page 596
Technical Data:
Temperature Range:
HAR/IEC:
UL/CSA:
Stranding:
-40
o
C to +70
o
C
-40
o
C to +105
o
C
Test Voltage:
Approvals:
UL:
CSA:
Additional:
Fine wire per VDE 0295, Class 5
2500V
H05V-K:
AWM Style 1007 + 1569
H07V-K:
1063 MTW Listed, 1015 AWM
TEW
<HAR> H05V-K & H07V-K
This wiring material conforms to the European H07V2-K
standard for +90
o
C PVC
Nominal Voltage:
HAR/IEC:
UL/CSA:
Part
Number
H05V-K:
300/500V
300V
Nominal Outer
Diameter
inches
mm
Copper
Weight
lbs/mft
H07V-K:
450/750V
600V
Approx.
Weight
lbs/mft
kg/km
Part
Number
Nominal Outer
Diameter
inches
mm
Copper
Weight
lbs/mft
Approx.
Weight
lbs/mft
kg/km
H05V-K
22 AWG (0.50 mm
2
)
41804..
20 AWG (0.75 mm
2
)
41805..
18 AWG (1.00 mm
2
)
41806..
H07V-K
16 AWG (1.50 mm
2
)
41604..
14 AWG (2.50 mm
2
)
41605..
12 AWG (4 mm
2
)
41606..
10 AWG (6 mm
2
)
41607..
.087
.094
.098
.122
.146
.173
.193
2.2
2.4
2.5
3.1
3.7
4.4
4.9
3
5
6
10
16
26
39
5.8
7.5
9.1
13.4
20.8
30.2
42.3
9
11
14
20
31
45
63
8 AWG (10 mm
2
)
41608..
6 AWG (16 mm
2
)
*41609..
4 AWG (25 mm
2
)
41610..
2 AWG (35 mm
2
)
41611..
1 AWG (50 mm
2
)
*41612..
2/0 AWG (70 mm
2
)
*41613..
3/0 AWG (95 mm
2
)
41614..
4/0 AWG (120 mm
2
)
41615..
.268
.350
.398
.449
.551
.622
.713
.764
6.8
8.9
10.1
11.4
14.0
15.8
18.1
19.4
65
103
161
226
323
452
613
774
80.7
124.3
174.8
242.0
359.6
494.0
625.1
779.7
120
185
260
360
535
735
930
1160
NOTE:
To develop the Lapp part number - add the double digit color code to the above part number prefix.
For example: 16AWG H07V-K Green/ Yellow: 4160400
* In accordance to the HAR standards X07V-K without “HAR”- printing. ** For these colors no HAR-approval for 1.5 mm
2
or larger
800-774-3539 • www.lappusa.com • www.lappcanada.com • www.lappmexico.com
209
