SBR30100CT
Green Products
SBR30100CT SCHOTTKY RECTIFIER
Applications:
Switching power supply
Converters
Free-Wheeling diodes
Reverse battery protection
Features:
150℃ TJ operation
Center tap configuration
Low forward voltage drop
High purity, high temperature epoxy encapsulation for enhanced
mechanical strength and moisture resistance
High frequency operation
Guard ring for enhanced ruggedness and long term reliability
This is a Pb
−
Free Device
All SMC parts are traceable to the wafer lot
Additional testing can be offered upon request
Mechanical Dimensions (In mm / Inches) and Marking:
Dimensions in
millimeters
Typical
4.57
1.27
2.69
0.81
1.27
0.38
15.24
9.00
10.16
2.54
5.06
6.24
13.56
3.5
3.84
2.74
7°
3°
4°
Symbol
A
A1
A2
b
b1
c
D
D1
E
e
e1
H1
L
L1
ΦP
Q
Θ1
Θ2
Θ3
Min
4.42
1.17
2.59
0.71
0.36
14.94
8.85
10.01
Max
4.72
1.37
2.89
0.96
0.61
15.54
9.15
10.31
6.04
12.7
3.74
2.54
6.44
13.78
4.04
2.94
OPTION1 (HD)
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0914, Rev. -
SBR30100CT
Green Products
OPTION2 (CJ)
TO-220AB
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0914, Rev. -
SBR30100CT
Green Products
Marking Diagram:
Where XXXXX is YYWWL
SBR
30
100
CT
SSG
YY
WW
L
= Device Type
= Forward Current (30A)
= Reverse Voltage (100V)
= Configuration
= SSG
= Year
= Week
= Lot Number
Cautions：
Molding resin
Epoxy resin UL:94V-0
Ordering Information:
Device
SBR30100CT
Package
TO-220AB (Pb-Free)
Shipping
50 pcs / tube
For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specification.
Maximum Ratings:
Characteristics
Peak Inverse Voltage
Max. Average Forward
Peak Repetitive Forward
Current(per leg)
Max. Peak One Cycle
Non-Repetitive Surge Current
(per leg)
I
FSM
Symbol
V
RWM
I
F(AV)
I
FRM
Condition
-
50% duty cycle @T
C
= 133°C,
rectangular wave form
Rated V
R
square wave,
20KHz T
C
= 133°C
Surge applied at rated load
conditions halfwave, single
phase,60Hz
(86) 25-87123907
•
150
A
Max.
100
30
20
Units
V
A
A
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0914, Rev. -
SBR30100CT
Green Products
Electrical Characteristics:
Characteristics
Max. Forward Voltage Drop
(per leg) *
Max. Reverse Current (per
leg) *
Symbol
V
F1
V
F2
I
R1
I
R2
Max. Junction Capacitance
(per leg)
Max. Voltage Rate of Change
*
Pulse Width < 300µs, Duty Cycle <2%
Condition
@ 15 A, Pulse, T
J
= 25
°C
@ 15 A, Pulse, T
J
= 125
°C
@V
R
= rated V
R
T
J
= 25
°C
@V
R
= rated V
R
T
J
= 125
°C
@V
R
= 5V, T
C
= 25
°C
f
SIG
= 1MHz
-
Max.
0.90
0.80
1.0
6.0
400
10,000
Units
V
V
mA
mA
pF
V/μs
C
T
dv/dt
Thermal-Mechanical Specifications:
Characteristics
Max. Junction Temperature
Max. Storage Temperature
Maximum Thermal
Resistance Junction to Case
Maximum Thermal
Resistance, Case to Heat
Sink
Maximum Thermal
Resistance, Case to Heat
Sink
Approximate Weight
Case Style
wt
R
θCS
Mounting surface, smooth and
greased
-
ITO-220AB
0.50
2.0
°C/W
g
R
θJA
DC operation
50
°C/W
Symbol
T
J
T
stg
R
θJC
DC operation
Condition
-
-
Specification
-55 to +150
-55 to +150
3.0
Units
°C
°C
°C/W
•
FAX (86) 25-87123900
•
World Wide Web Site - http://www.sangdest.com.cn
•
E-Mail Address - sales@ sangdest.com.cn
•
•
Weiqi Street, Airport Development Zone, Jiangning District, Nanjing, China 211113
(86) 25-87123907
•
SANGDEST
MICROELECTRONICS
Technical Data
Data Sheet N0914, Rev. -
SBR30100CT
Green Products
Instantaneous Reverse Current (mA)
10000
Junction Capacitance (PF)
10
1
0.1
0.01
0.001
1000
TJ=125℃
TJ=25℃
100
TJ=25℃
0.0001
10
20
30
40
50
60
70
80
90
100
Percent of Rated Peak Reverse Voltage (%)
10
0
5
10
15
20
25
30
35
40
Reverse Voltage (V)
Fig.1-Typical Junction Capacitance
Fig.2-Typical Reverse Characteristics
Instantaneous Forward Current-
IF(A)
100
TJ=125℃
10
TJ=25℃
1
0.4
0.5
0.6
0.7
0.8
0.9
1
