AMORPHOUS / DUST CHOKE COILS
Amorphous metal and NIPPON CHEMI-CON Amorphous Choke Coil
The amorphous metal has non crystalline structure generated by cooling molten metal
rapidly. Due to the amorphous structure, the amorphous metal has excellent magnetic,
mechanical, and chemical features in comparison with conventional metallic substances.
NIPPON CHEMI-CON started developing amorphous components for electronic and
electric equipment by making full use of the material and process technologies at its early
stages and has continued the synthetic research and development to optimally match the
amorphous choke coils with the material features and their applications through a vari-
ety of characteristics. NIPPON CHEMI-CON will help the customers design smaller and
higher performance products by supplying excellent amorphous choke coils through the
sophisticated production technology and manufacturing know-how.
STANDARD SPECIFICATIONS
◆General
Specification of Toroidal Coil
Items
Operating temperature range
*1
Storage temperature range
Operating humidity range
*1
Storage humidity range
Operating frequency range
*2
Temperature rise
*3
Insulation type
Incombustibility
Amorphous coils
Rated value
Dust coils
Rated value
-40 to 120
℃
(Coating type)
-40 to 130
℃
(Case type)
-40 to 120
℃
(Coating type)
-40 to 130
℃
-40 to 130
℃
(Case type)
20 to 95%RH
20 to 80%RH
20kHz to 500kHz
40K or less
Type A(105
℃
) Coating type
Type B (130
℃
)
Type B(130
℃
) Case type
UL 94 V-0
-40 to 130
℃
*1 Temperature on the coil surface including the temperature rise
in installation. Never use the coil at a temperature exceeding the
rated temperature range.
*2 Recommended range. When infra-acoustic frequency component
is impressed, a beat sound sometimes occurs.
*3 The temperature rise on the coil surface at the rated d.c. current.
Note carefully that the temperature of the core may exceed the operating temperature range
depending on the circumference condition even if the coil is used in the specification ranges
described above.
◆DIMENSIONS
Side view
D2
W
D2
D2
W
a
W
L
D1
D1
Bottom view
a
D1
*Start and end of wire
*
D2
L
L
W
L
D1
* Start and end of wire
Maximum outer diameter : D1(Vertical), D2(Horizontal)
Maximum width : W
Total lead length : L=30±3mm
Soldering boundary : a=1.5mmMAX
*The bottom of the core or coil ( ) is defined
as base surface.
Maximum outer diameter : D1(Vertical), D2(Horizontal)
Maximum width : W
Total lead length *1 : L=15±3mm
Soldering boundary *1 : a=1.5mmMAX
*1 The bottom of the core or coil ( ) is defined
as base surface.
Maximum outer diameter *1 : D2
Maximum width *2 : D1
Maximum width : W
Total lead length *2 : L=13±2mm
Soldering boundary : a=0mm MAX
*1 Indicates the maximum dimension of coil or stand.
*2 The bottom of the pedestal ( ) is defined
as base surface.
a
Maximum outer diameter *1 : D1, D2
Maximum width : W
Total lead length *2 : L=13±2mm
Soldering boundary : a=0mm MAX
*1 Indicates the maximum dimension of coil or stand.
*2 The bottom of the pedestal ( ) is defined
as base surface.
◆Notes
on use
that the lead wire may not be subject to excess force and also may not be bent repeatedly because the wire is made of
copper.
●
Never make the coil hit on a hard and/or sharp substance. If so, the coating of the coils may be damaged to ruin the perfor-
mance of the coil.
●
Contact NIPPON CHEMI-CON for how to clean the substrate on which the coil is mounted.
●
When infra-acoustic frequency component is impressed, a beat sound sometimes occurs.
●
Regarding compliance for EU REACH Regulation
(1) According to the content of REACH handbook (Guidance on requirements for substances in articles which is published on
May 2008), our electronic components are "articles without any intended release". Therefore they are not applicable for
"Registration" for EU REACH Regulation Article 7 (1).
Reference: Electrolytic Condenser Investigation Society
"Study of REACH Regulation in EU about Electrolytic Capacitor" (publicized on 13 March 2008)
(2) Nippon Chemi-Con develops the products without substance of very high concern(SVHC).DEHP(CASNo.117-81-7) was
contained as some covering material, Nippon Chemi-Con abolished use of DEHP totally at June, 2011.
●
Note
Product specifications in this catalog are subject to change without notice.Request our product specifications before purchase and/or use. Please use our products based on the information contained in this catalog and product specifications.
(1/2)
CAT. No. E1008M
a
AMORPHOUS / DUST CHOKE COILS
Miniatur-
Thin
ization
type
Low
loss
Low
cost
Series
Major uses
Switching mode power supplies
DC-DC converter
Normal mode line filter
Switching mode power supplies
Step up and down converter
Large
capacity
Classification
CM
CMJ
AM
AW
TM
BM
DM
SM
FM
Toroidal with gap
Harmonic counter-measure active filter
Normal mode line filter
Harmonic counter-measure active filter
Uninterruptible power supply system (UPS)
Switching mode power supplies
DC-DC converter
Normal mode line filter
Switching mode power supplies
DC-DC converter
Normal mode line filter
DC-DC converter
Switching mode power supplies
Harmonic counter-measure active filter
DC-DC converter
Switching mode power supplies
Line filter for inverter or large power supply
High frequency transformer
Toroidal without gap
Dust
Package
Common mode
Accessories
AMORPHOUS CHOKE COIL Characteristics
Coil Design Request
GLOBAL CODE SYSTEM
The current parts numbering system is changed to new system for global coding.
Your cooperation will be very much appreciated.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
L B TM 0 1 0 3 0 0 N 6 - V 0 E
Solder control code
⑥
Specifications control code
⑤
Mounting Direction
④
Core Abbreviation
③
Rated Inductance
②
Rated Current
①
Series
Section code
Class code
①
Rated
Current code
②
Rated Inductance code
③
Core Abbreviation code
④
Mounting Direction code
Code Rated Inductance
0.5
µ
H
0R5
1
µ
H
010
10
µ
H
100
100
µ
H
101
1000
µ
H
102
⑥
Solder
Code Rated Current
0.5A
0R5
1A
001
10A
010
100A
100
Code Core Abbreviation
N6
N6-
JRH
JRH
Code
Mounting Direction
V
Vertical
H
Horizontal
D
Vertical pedestal
B
Horizontal pedestal
Y
Vertical pedestal with pins
W Horizontal pedestal with pins
⑤
Specifications
control code
control code
Code Specifications
Standard
0
Custom
1
Code
0
E
Specifications
Not Pb free
Pb free
COIL SERIES GUIDE
AW
Toroidal with gap
(For active filter)
AM
Toroidal with gap
(For active filter)
(For smoothing output)
CM
Toroidal with gap
CMJ
Toroidal with gap
(For step up converter)
TM
Toroidal without gap
(For smoothing output)
BM
Toroidal without gap
(For smoothing output)
DM
Dust
SM
Thin package
(For smoothing output)
(For smoothing output&active filter)
1
10
100
1k
10k
Power capacity of applied power supply Po [W]
(2/2)
CAT. No. E1008M
