DC0000086: DescriptionFederleiste 8mm SMD, 50 polig Female 8mm SMD, 50 contacts; File Size94KB，1 Pages; ManufacturerERNI; Websitehttp://www.erni.com

Download Datasheet View All

DC0000086 Overview

Federleiste 8mm SMD, 50 polig Female 8mm SMD, 50 contacts

Preview

Download Datasheet

View All

26,55

6,5

Ansaughaube

5,5

hood

4,15

Verpackt in Gurtverpackung

Tape on Reel Packaging

Verpackungseinheit: 260 Stück

Packaging unit: 260 pcs

9,4

8,5

7,8

330

0,7

Mitte Steckgesicht

0,6

0,5

0,8

0,75

center matingface

b25

Einzelheit X

M 20:1

3,85

1,5

Abspulrichtung -

Reel off Direction

24 x 1 = 24

25,3

a25

0,05

signaling contact

Leiterplatten-Layout Vorschlag /

PCB-layout proposal

±0,03

0,85

1.)

0,65

0,7

±0,03

8 x 3 = 24

0,8

1.)

0,9

±0,03

Anforderungsstufe 1

Performance Level 1

Kontaktbereich vergoldet

Mating Area gold plating

Anschlussbereich verzinnt 4-6 µm

Terminal Area 4-6 µm tin plating

Koplanarität der Anschlüsse

≤

0,1 mm

Coplanarity Area of Termination

≤

0,1 mm

4,45

1,5

Proprietary notice pursuant to ISO 16016 to be observed.

Information:

Tolerances

All Dimensions

in mm

Scale

5:1

0,7

0,5

24 x 1 = 24

1.) Durchmesser des Bohrers /

Drill tool

0,85

Only for Information.

To ensure that this is the latest

version of this drawing, please

contact one of the ERNI companies

before using.

Index

24.04.2013

Date

Designation

Subject to modification without

prior notice.

Drawing will not be updated.

Federleiste 8mm SMD, 50 polig

Female 8mm SMD, 50 contacts

www.ERNI.com

Class

224514

MSPEED
