SK32SMA ... SK315SMA
SK32SMA ... SK315SMA
Surface Mount Schottky Rectifier Diodes
Schottky-Gleichrichterdioden für die Oberflächenmontage
Version 2014-01-16
5
± 0.2
2.2
± 0.2
2.1
± 0.2
Nominal current – Nennstrom
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
Plastic case
Kunststoffgehäuse
Weight approx. – Gewicht ca.
Plastic material has UL classification 94V-0
Gehäusematerial UL94V-0 klassifiziert
Standard packaging taped and reeled
Standard Lieferform gegurtet auf Rolle
3A
20...150 V
~ SMA
~ DO-214AC
0.07g
1
2.7
± 0.2
± 0.3
0.15
Type
Typ
4.5
± 0.3
Dimensions - Maße [mm]
Maximum ratings and Characteristics
Type
Typ
SK32SMA
SK33SMA
SK34SMA
SK35SMA
SK36SMA
SK38SMA
SK310SMA
SK315SMA
Repetitive peak reverse voltage
Periodische Spitzensperrspannung
V
RRM
[V]
20
30
40
50
60
80
100
150
Surge peak reverse voltage
Stoßspitzensperrspannung
V
RSM
[V]
20
30
40
50
60
80
100
150
T
T
= 100°C
f > 15 Hz
T
A
= 25°C
T
A
= 25°C
1.5
±0.1
Grenz- und Kennwerte
Forward voltage
Durchlass-Spannung
V
F
[V]
1
)
< 0.50
< 0.50
< 0.50
< 0.70
< 0.70
< 0.85
< 0.85
< 0.87
I
FAV
I
FRM
I
FSM
i
2
t
T
S
V
R
= V
RRM
V
R
= V
RRM
I
R
I
R
R
thA
R
thT
3A
20 A
2
)
80/90 A
32 A
2
s
-50...+150°C
-50...+150°C
< 200 µA
< 10 mA
< 70 K/W
3
)
< 30 K/W
Max. average forward rectified current, R-load
Dauergrenzstrom in Einwegschaltung mit R-Last
Repetitive peak forward current – Periodischer Spitzenstrom
Peak forward surge current, 50/60 Hz half sine-wave
Stoßstrom für eine 50/60 Hz Sinus-Halbwelle
Rating for fusing, t < 10 ms – Grenzlastintegral, t < 10 ms
Operating junction temperature – Sperrschichttemperatur
Storage temperature – Lagerungstemperatur
Leakage current
Sperrstrom
Thermal resistance junction to ambient air
Wärmewiderstand Sperrschicht – umgebende Luft
Thermal resistance junction to terminal
Wärmewiderstand Sperrschicht − Anschluss
1
2
3
T
j
T
j
= 25°C
T
j
= 100°C
I
F
= 3 A, T
j
= 25°C
Max. temperature of the terminals T
T
= 100°C – Max. Temperatur der Anschlüsse T
T
= 100°C
Mounted on P.C. board with 25 mm
2
copper pads – Montage auf Leiterplatte mit 25 mm
2
Kupferbelag (Lötpads)
http://www.diotec.com/
© Diotec Semiconductor AG
1
SK32SMA ... SK315SMA
120
[%]
100
10
80
SK35...36SMA
10
2
[A]
SK32...34SMA
60
1
SK38...310SMA
40
10
-1
20
I
FAV
0
0
T
T
50
100
150
[°C]
I
F
10
-2
SK315
0
V
F
0.4
0.6
[V]
1.0
Rated forward current vs. temp. of the terminals
Zul. Richtstrom in Abh. v. d. Temp. der Terminals
Forward characteristics (typical values)
Durchlasskennlinien (typische Werte)
10
[pF]
T
j
= 25°C
f = 1.0 MHz
[mA]
1
T
j
= 125°C
T
j
= 100°C
10
-1
T
j
= 50°C
10
-2
C
j
I
R
[V]
10
-3
0
T
j
= 25°C
V
R
Junction capacitance vs. reverse voltage (typical)
Sperrschichtkapazität in Abh. v.d. Sperrspg. (typ.)
V
RRM
40
60
[%]
100
Typ. instantaneous leakage current vs. rev. voltage
Typ. Sperrstrom (Augenblickswert) ü. Sperrspannung
10
2
[A]
10
î
F
1
1
10
10
2
[n]
10
3
Peak forward surge current versus number of cycles at 50 Hz
Durchlaß-Spitzenstrom in Abh. von der Zahl der Halbwellen bei 50 Hz
2
