AP4455GYT-HF
Halogen-Free Product
Advanced Power
Electronics Corp.
▼
Simple Drive Requirement
▼
Small Size & Lower Profile
▼
RoHS Compliant & Halogen-Free
P-CHANNEL ENHANCEMENT MODE
POWER MOSFET
D
G
S
BV
DSS
R
DS(ON)
I
D
D
-30V
21mΩ
-10.6A
Description
D
Advanced Power MOSFETs from APEC provide the designer with the
best combination of fast switching, ruggedized device design, low on-
resistance and cost-effectiveness.
The PMPAK
®
3x3 package is special for DC-DC converters application
and lower 1.0mm profile with backside heat sink.
S
S
D
D
S
G
PMPAK
®
3x3
Absolute Maximum Ratings
Symbol
V
DS
V
GS
I
D
@T
A
=25℃
I
D
@T
A
=70℃
I
DM
P
D
@T
A
=25℃
T
STG
T
J
Parameter
Drain-Source Voltage
Gate-Source Voltage
Continuous Drain Current
3
, V
GS
@ 10V
Continuous Drain Current , V
GS
@ 10V
Pulsed Drain Current
1
Total Power Dissipation
Storage Temperature Range
Operating Junction Temperature Range
3
Rating
-30
+20
-10.6
-8.5
-40
3.57
-55 to 150
-55 to 150
Units
V
V
A
A
A
W
℃
℃
Thermal Data
Symbol
Rthj-c
Rthj-a
Parameter
Maximum Thermal Resistance, Junction-case
Maximum Thermal Resistance, Junction-ambient
3
Value
5
35
Unit
℃/W
℃/W
1
201108262
Data and specifications subject to change without notice
AP4455GYT-HF
Electrical Characteristics@T
j
=25
o
C(unless otherwise specified)
Symbol
BV
DSS
R
DS(ON)
V
GS(th)
g
fs
I
DSS
I
GSS
Q
g
Q
gs
Q
gd
t
d(on)
t
r
t
d(off)
t
f
C
iss
C
oss
C
rss
R
g
Parameter
Drain-Source Breakdown Voltage
Static Drain-Source On-Resistance
2
Gate Threshold Voltage
Forward Transconductance
Drain-Source Leakage Current
Gate-Source Leakage
Total Gate Charge
Gate-Source Charge
Gate-Drain ("Miller") Charge
Turn-on Delay Time
Rise Time
Turn-off Delay Time
Fall Time
Input Capacitance
Output Capacitance
Reverse Transfer Capacitance
Gate Resistance
Test Conditions
V
GS
=0V, I
D
=-250uA
V
GS
=-10V, I
D
=-8A
V
GS
=-4.5V, I
D
=-5A
V
DS
=V
GS
, I
D
=-250uA
V
DS
=-10V, I
D
=-8A
V
DS
=-24V, V
GS
=0V
V
GS
=+20V, V
DS
=0V
I
D
=-8A
V
DS
=-15V
V
GS
=-4.5V
V
DS
=-15V
I
D
=-1A
R
G
=3.3Ω
V
GS
=-10V
V
GS
=0V
V
DS
=-15V
f=1.0MHz
f=1.0MHz
Min.
-30
-
-
-1
-
-
-
-
-
-
-
-
-
-
-
-
-
3
Typ.
-
15
21.3
-1.6
20
-
-
19
4.5
9
10
6
60
40
280
250
6
Max. Units
-
21
36
-3
-
-10
+30
30
-
-
-
-
-
-
-
-
12
V
mΩ
mΩ
V
S
uA
uA
nC
nC
nC
ns
ns
ns
ns
pF
pF
pF
Ω
1700 2720
Source-Drain Diode
Symbol
V
SD
t
rr
Q
rr
Parameter
Forward On Voltage
2
Reverse Recovery Time
Reverse Recovery Charge
Test Conditions
I
S
=-2.9A, V
GS
=0V
I
S
=-8A,
V
GS
=0
V
,
dI/dt=100A/µs
Min.
-
-
-
Typ.
-
23
13
Max. Units
-1.2
-
-
V
ns
nC
Notes:
1.Pulse width limited by Max. junction temperature.
2.Pulse test
3.Surface mounted on 1 in
2
copper pad of FR4 board, t <10sec, 85
o
C/W at steady state.
THIS PRODUCT IS SENSITIVE TO ELECTROSTATIC DISCHARGE, PLEASE HANDLE WITH CAUTION.
USE OF THIS PRODUCT AS A CRITICAL COMPONENT IN LIFE SUPPORT OR OTHER SIMILAR SYSTEMS IS NOT AUTHORIZED.
APEC DOES NOT ASSUME ANY LIABILITY ARISING OUT OF THE APPLICATION OR USE OF ANY PRODUCT OR CIRCUIT DESCRIBED
HEREIN; NEITHER DOES IT CONVEY ANY LICENSE UNDER ITS PATENT RIGHTS, NOR THE RIGHTS OF OTHERS.
APEC RESERVES THE RIGHT TO MAKE CHANGES WITHOUT FURTHER NOTICE TO ANY PRODUCTS HEREIN TO IMPROVE
RELIABILITY, FUNCTION OR DESIGN.
2
AP4455GYT-HF
100
80
80
-I
D
, Drain Current (A)
-I
D
, Drain Current (A)
-10V
T
A
=25 C
-7.0V
-6.0V
-5.0V
V
G
= -4.0V
o
T
A
= 150
o
C
60
-10V
-7.0V
-6.0V
-5.0V
V
G
= -4.0V
60
40
40
20
20
0
0
2
4
6
8
10
0
0
2
4
6
8
10
-V
DS
, Drain-to-Source Voltage (V)
-V
DS
, Drain-to-Source Voltage (V)
Fig 1. Typical Output Characteristics
Fig 2. Typical Output Characteristics
25
1.6
23
I
D
= -5 A
T
A
=25
℃
1.4
I
D
=-8A
V
G
=-10V
21
Normalized R
DS(ON)
2
4
6
8
10
R
DS(ON)
(m
Ω
)
1.2
19
1.0
17
0.8
15
13
0.6
-50
0
50
100
150
-V
GS
, Gate-to-Source Voltage (V)
T
j
, Junction Temperature (
o
C)
Fig 3. On-Resistance v.s. Gate Voltage
Fig 4. Normalized On-Resistance
v.s. Junction Temperature
2.0
12
I
D
= -250uA
10
1.6
8
Normalized -V
GS(th)
(V)
-I
S
(A)
1.2
T
j
=150
o
C
6
T
j
=25
o
C
0.8
4
0.4
2
0
0.0
0
0.2
0.4
0.6
0.8
1
1.2
1.4
-50
0
50
100
150
-V
SD
, Source-to-Drain Voltage (V)
T
j
, Junction Temperature ( C)
o
Fig 5. Forward Characteristic of
Reverse Diode
Fig 6. Gate Threshold Voltage v.s.
Junction Temperature
3
AP4455GYT-HF
10
2400
f=1.0MHz
I
D
= -8 A
V
DS
= -15 V
-V
GS
, Gate to Source Voltage (V)
8
2000
C
iss
6
C (pF)
1600
1200
4
800
2
400
C
oss
C
rss
1
5
9
13
17
21
25
29
0
0
10
20
30
40
0
Q
G
, Total Gate Charge (nC)
-V
DS
, Drain-to-Source Voltage (V)
Fig 7. Gate Charge Characteristics
Fig 8. Typical Capacitance Characteristics
100
1
Operation in this area
limited by R
DS(ON)
10
100us
Normalized Thermal Response (R
thja
)
Duty factor=0.5
0.2
0.1
0.1
-I
D
(A)
1ms
1
0.05
10ms
100ms
1s
0.02
0.01
P
DM
0.01
Single Pulse
t
T
Duty factor = t/T
Peak T
j
= P
DM
x R
thja
+ T
a
R
thia
=85
℃/W
0.1
T
A
=25
o
C
Single Pulse
0.01
0.01
0.1
1
10
DC
0.001
100
0.0001
0.001
0.01
0.1
1
10
100
1000
-V
DS
, Drain-to-Source Voltage (V)
t , Pulse Width (s)
Fig 9. Maximum Safe Operating Area
Fig 10. Effective Transient Thermal Impedance
50
16
V
DS
= -5V
40
-I
D
, Drain Current (A)
-I
D
, Drain Current (A)
T
j
=150 C
o
T
j
=25 C
T
j
= -40
o
C
o
12
30
8
20
4
10
0
0
0
1
2
3
4
5
6
25
50
75
100
125
150
-V
GS
, Gate-to-Source Voltage (V)
T
A
, Ambient Temperature ( C )
o
Fig 11. Transfer Characteristics
Fig 12. Maximum Continuous Drain
Current v.s. Ambient Temperature
4
