RoHS
SMD SHIELDED POWER CHIP INDUCTOR
PCSV65
Dimensions:
Inches
(mm)
.236±.008
(6.0±0.2)
.177 Max
(4.5 Max)
.071±0.118
(1.8±0.3)
XXX
.236±.008
(6.0±0.2)
.071±0.118
(1.8±0.3.)
Allied
Part
Number
Inductance
(µh)
Tolerance
(%)
Test
Freq.
KHz, 1V
RDC
m(Ω)
±30%
Isat
(A)
Typ.
Irms
(A)
Typ.
Features
• Magnetically Shielded Construction
• Low Profile
Electrical
Inductance Range:
1.0uh ~ 1000uh (other
values being added)
Tolerance:
Available in 20% and 30%
Operating Temp:
-40ºC ~ +125ºC
Isat:
Current at which the Inductance will drop
by no more then 30% of its initial value.
Irms:
Based on a temp rise of
∆
T = 40ºC
typical.
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 Min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC for 10 sec
PCSV65-1R0M-RC
PCSV65-1R5T-RC
PCSV65-1R8M-RC
PCSV65-2R2M-RC
PCSV65-2R3M-RC
PCSV65-3R0M-RC
PCSV65-3R3M-RC
PCSV65-3R6M-RC
PCSV65-3R9M-RC
PCSV65-4R5M-RC
PCSV65-4R7M-RC
PCSV65-5R1M-RC
PCSV65-5R6M-RC
PCSV65-6R3M-RC
PCSV65-6R8M-RC
PCSV65-100M-RC
PCSV65-150M-RC
PCSV65-180M-RC
PCSV65-220M-RC
PCSV65-270M-RC
PCSV65-330M-RC
PCSV65-470M-RC
PCSV65-560M-RC
PCSV65-680M-RC
PCSV65-101M-RC
PCSV65-221M-RC
PCSV65-331M-RC
PCSV65-102M-RC
1.0
1.5
1.8
2.2
2.3
3.0
3.3
3.6
3.9
4.5
4.7
5.1
5.6
6.3
6.8
10
15
18
22
27
33
47
56
68
100
220
330
1000
20
30
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
12
15
17
18.4
19
22
24
24
26
31
31
33
40
40
43
57
80
100
125
160
165
245
300
330
500
1300
1800
6000
12.2
10.4
9.6
8.8
8.8
7.8
7.5
7.5
7.0
6.7
6.7
6.0
5.8
5.5
5.3
4.5
3.4
3.1
3.0
2.5
2.3
1.9
1.7
1.6
1.3
.82
0.7
0.4
6.5
5.9
5.6
5.1
5.0
4.4
4.3
4.3
4.0
3.9
3.9
3.5
3.4
3.3
3.2
2.7
2.2
1.8
1.9
1.3
1.4
1.2
1.1
1.0
0.8
.38
.35
.22
Test Equipment
(L):
HP4284A
(RDC):
Chroma MilliOhm Meter 16502
Current:
HP4284A + HP42841A
Physical
Packaging:
1K per Tape and reel
Marking:
EIA Inductance Code.
All specifications subject to change without notice.
Land Pattern
.224
(5.7)
.079
(2.0)
.094
(2.4)
.079
(2.0)
949-356-1780
ALLIED COMPONENTS INTERNATIONAL
REVISED
15
09/25/2014
www.alliedcomponents.com
