SMD SEMI-SHIELDED POWER CHIP INDUCTOR
PCSVLR80
Dimensions:
Inches
(mm)
.315±.008
(8.0±0.2)
.157±.008
(4.0±0.2)
.091±.012
(2.3±0.3)
XXX
.315±.008
(8.0±0.2)
.091±.012
(2.3±0.3)
.248
TYP
(6.3)
Allied
Part
Number
Inductance Tolerance
(
µh)
(%)
RDC
Test
Freq.
(mΩ)
KHz, 1V
±30%
Isat
(A)
(Max)
Irms
(A)
(Max)
Marking
Features
•
•
•
•
Semi Magnetically Shielded
High Current
Semi Magnetically Shielded
High Current
PCSVLR80-R90T-RC
PCSVLR80-1R0T-RC
PCSVLR80-1R4T-RC
PCSVLR80-1R5T-RC
PCSVLR80-2R0M-RC
PCSVLR80-2R2M-RC
PCSVLR80-2R5M-RC
PCSVLR80-3R3M-RC
PCSVLR80-4R7M-RC
PCSVLR80-5R6M-RC
PCSVLR80-6R8M-RC
PCSVLR80-100M-RC
PCSVLR80-120M-RC
PCSVLR80-150M-RC
PCSVLR80-180M-RC
PCSVLR80-220M-RC
PCSVLR80-330M-RC
PCSVLR80-470M-RC
PCSVLR80-680M-RC
PCSVLR80-101M-RC
PCSVLR80-121M-RC
PCSVLR80-151M-RC
PCSVLR80-221M-RC
PCSVLR80-271M-RC
PCSVLR80-821M-RC
0.9
1.0
1.4
1.5
2.0
2.2
2.5
3.3
4.7
5.6
6.8
10
12
15
18
22
33
47
68
100
120
150
220
270
820
30
30
30
30
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
7.0
7.5
9.0
11
11.5
13
15
18
23
25
38
45
50
7.0
7.5
9.0
11
11.5
13
15
18
23
25
38
45
12.42
11.70
9.72
9.00
8.64
8.28
7.38
6.75
5.40
5.13
4.86
3.87
3.42
3.24
2.79
2.52
2.07
1.71
1.71
1.53
0.99
0.90
0.84
0.74
0.36
7.24
7.15
7.02
6.93
6.66
6.48
5.67
5.40
4.95
4.68
4.59
3.42
3.15
2.88
2.43
2.34
1.80
1.57
1.30
0.99
0.99
0.81
0.54
0.49
0.34
R90
1R0
1R4
1R5
2R0
2R2
2R5
3R3
4R7
5R6
6R8
10
12
15
18
22
33
47
68
100
120
150
220
270
820
Electrical
Inductance Range:
0.9µh ~ 820µh (other
values being added)
Tolerance:
Available in 20% & 30%
Operating Temp:
-55ºC ~ +125ºC
Isat:
Current at which the Inductance will drop
by no more then 30% of its initial value.
Irms:
Based on a temp rise of
∆
T = 40ºC
typical.
Resistance to Soldering Heat
Pre-Heat 150ºC, 1 Min.
Solder Composition:
Sn/Ag3.0/Cu0.5
Solder Temp:
260ºC +/- 5ºC for 10 sec
Test Equipment
(L):
HP4284A + HP42841A
(RDC):
Chroma MilliOhm Meter Mode 16502
Current:
HP4284A + HP42841A
Physical
Packaging:
1000 per 13” Tape and Reel
Marking:
AS noted
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
11/12/13
15
www.alliedcomponents.com
