ASPC80
Power Shielded Inductors
Inches
(mm)
Dimensions:
1.00 Max
(25.4)
20 AWG/TCW
100K
0.550 Max
(13.97)
1.15 Nominal
(29.21)
Features
• Magnetically Shielded
• Epoxy End Caps for added Lead
Strength and Protection
Allied
Part
Number
L
(µh)
DCR
(Ω)
Max
Rated
Current
(AC Amps)
Allied
Part
Number
L
(µh)
DCR
(Ω)
Max
Rated
Current
(AC Amps)
Electrical
Inductance Range:
1.0µh ~ 680mH
Tolerance:
10% across entire range
Tighter tolerances available
Test Frequency:
1.0µh ~ 82,000µh Tested @ 1KHZ, HP4263B
100,000µh ~ 680,000µh Tested @ 1KHZ, 1V
HP4263B
Operating Temp:
-55ºC ~ +125ºC
Current Rating:
Based on a .33 watt power
dissipation for approximately 20ºC Temp Rise
Test Equipment
Inducatance:
HP4263B & HP4282 As noted
above.
Current:
11021 Current Source with DCR Meter
DCR:
HP4263B
Physical
Packaging:
Bulk Only
Marking:
EIA Inductance Code
ASPC80-1R0K-RC
ASPC80-1R2K-RC
ASPC80-1R5K-RC
ASPC80-1R8K-RC
ASPC80-2R2K-RC
ASPC80-2R7K-RC
ASPC80-3R3K-RC
ASPC80-3R9K-RC
ASPC80-4R7K-RC
ASPC80-5R6K-RC
ASPC80-6R8K-RC
ASPC80-8R2K-RC
ASPC80-100K-RC
ASPC80-120K-RC
ASPC80-150K-RC
ASPC80-180K-RC
ASPC80-220K-RC
ASPC80-270K-RC
ASPC80-330K-RC
ASPC80-390K-RC
ASPC80-470K-RC
ASPC80-560K-RC
ASPC80-680K-RC
ASPC80-820K-RC
ASPC80-101K-RC
ASPC80-121K-RC
ASPC80-151K-RC
ASPC80-181K-RC
ASPC80-221K-RC
ASPC80-271K-RC
ASPC80-331K-RC
ASPC80-391K-RC
ASPC80-471K-RC
ASPC80-561K-RC
ASPC80-681K-RC
ASPC80-821K-RC
ASPC80-102K-RC
ASPC80-122K-RC
ASPC80-152K-RC
ASPC80-182K-RC
ASPC80-222K-RC
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
0.0066
0.007
0.008
0.008
0.008
0.009
0.009
0.009
0.012
0.012
0.012
0.013
0.013
0.013
0.014
0.017
0.02
0.02
0.022
0.023
0.024
0.027
0.028
0.029
0.030
0.034
0.036
0.044
0.047
0.049
0.052
0.053
0.058
0.063
0.068
0.080
0.091
0.110
0.116
0.130
0.177
1.50
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.40
1.39
1.36
1.35
1.35
1.35
1.35
1.35
1.35
1.35
1.35
1.35
1.30
1.30
1.30
1.30
1.30
1.30
1.30
1.25
1.25
1.25
1.12
ASPC80-272K-RC
ASPC80-332K-RC
ASPC80-392K-RC
ASPC80-472K-RC
ASPC80-562K-RC
ASPC80-682K-RC
ASPC80-822K-RC
2700
3300
3900
4700
5600
6800
8200
L
(mH)
0.190
0.213
0.287
0.364
0.440
0.562
0.700
1.12
1.12
0.88
0.88
0.707
0.556
0.556
ASPC80-103K-RC
ASPC80-123K-RC
ASPC80-153K-RC
ASPC80-183K-RC
ASPC80-223K-RC
ASPC80-273K-RC
ASPC80-333K-RC
ASPC80-393K-RC
ASPC80-473K-RC
ASPC80-563K-RC
ASPC80-683K-RC
ASPC80-823K-RC
ASPC80-104K-RC
ASPC80-124K-RC
ASPC80-154K-RC
ASPC80-184K-RC
ASPC80-224K-RC
ASPC80-274K-RC
ASPC80-334K-RC
ASPC80-394K-RC
ASPC80-474K-RC
ASPC80-564K-RC
ASPC80-680K-RC
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
0.741
0.827
1.10
1.26
1.67
1.92
2.78
3.48
4.32
5.44
6.80
7.20
8.50
10.56
12.24
13.68
24
27
32
37
39.48
46.68
56.80
0.437
0.437
0.350
0.227
0.224
0.224
0.224
0.224
0.224
0.224
0.224
0.176
0.176
0.138
0.138
0.138
0.110
0.088
0.080
0.071
0.071
0.071
0.071
All specifications subject to change without notice.
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
09/03/10
www.alliedcomponents.com
