QEB75 SERIES
75 WATTS
FEATURES
•
75 WATTS MAXIMUM OUTPUT POWER
•
SINGLE OUTPUT UP TO 25A
•
COMPACT 2.28 X 1.45 X 0.50 INCH PACKAGE
•
HIGH EFFICIENCY UP TO 90%
•
2:1 WIDE INPUT VOLTAGE RANGE
•
FIXED SWITCHING FREQUENCY
•
INDUSTRY STANDARD FOOTPRINT
•
NO MINIMUM LOAD REQUIRED
•
ADJUSTABLE OUTPUT VOLTAGE
•
UNDER-VOLTAGE LOCKOUT
•
INPUT TO OUTPUT ISOLATION: 1600VDC
•
UL60950-1, EN60950-1, & IEC60950-1 SAFETY APPROVALS
•
CE MARKED
•
COMPLIANT TO RoHS II & REACH
DC-DC CONVERTER
APPLICATIONS
Wireless Network
Telecom/Datacom
Industry Control System
Distributed Power Architectures
Semiconductor Equipment
OPTIONS
Positive logic Remote on/off, Pin length
DESCRIPTION
QEB75 single output DC/DC converters provide up to 75 watts of output power in
an industry standard quarter-brick package and footprint. These units are
specifically designed to meet the power needs of low-voltage silicone. All models
feature a wide input range, trimmable output voltage and a 25A current rating.
T E C H N I C A L S P E C I F I C AT I O N
OUTPUT SPECIFICATIONS
Output power
Voltage accuracy
Minimum load
Voltage adjustability
Line regulation
Load regulation
Remote Sense
(Note 5)
LL to HL at Full Load
No load to Full Load
All specifications are typical at nominal input, full load and 25ºC otherwise noted
INPUT SPECIFICATIONS
75 Watts, max. Input voltage range
± 1.5%
Input filter
0%
+ 10% , -20% Input surge voltage
±0.2%
±0.3%
24VDC nominal input
48VDC nominal input
18 ~ 36VDC
36 ~ 75VDC
(Note 5)
10% of Vout(nom)
20MHz bandwidth
See table
Ripple and noise
(Measured with a 1µFM/C and a 10µFT/C)
0.02% / ºC, max.
Temperature coefficient
Transient response recovery time
Over voltage Protection threshold
(Non-latching Hiccup)
Over Current Protection threshold
Short circuit protection
25% load step change
200µs
120% of Vout(nom) max.
110% ~ 140% of Iout Rated
Continuous, automatics recovery
L-C type
24VDC input
50VDC 100ms, max.
48VDC input
100VDC 100ms, max.
Nominal input and
Power up
25ms
Start up time
constant resistive load
Remote ON/OFF
25ms
18VDC, max.
24VDC input
Start-up voltage
48VDC input
36VDC, max.
15VDC
24VDC input
Shutdown voltage
48VDC input
32VDC
Remote ON/OFF (Note 6)
Negative logic(Standard)
DC-DC ON
Short or 0V < Vr < 1.2V
Open or 3V < Vr < 15V
DC-DC OFF
DC-DC ON
Positive logic(Option)
Open or 3V < Vr < 15V
DC-DC OFF
Short or 0V < Vr < 1.2V
-0.5~1.0mA
Input current of remote control pin
Nominal input
Remote off state input current
Nominal input
2.5mA
GENERAL SPECIFICATIONS
Efficiency
Isolation voltage
Input to Output
1600 VDC, min. 1minute Storage temperature range
Input(Output) to Base-plate 1000 VDC, min. 1minute
Thermal shock
7
Isolation resistance
500VDC
10 ohms, min. Vibration
Isolation capacitance
Switching frequency
Safety approvals
QEB75-48S1P8
QEB75-48S2P5
QEB75-48S3P3
QEB75-48S05
2500 pF, max. Relative humidity(non-condensing)
270kHz±10%
Weight (approx)
MTBF (Note 1)
MIL-HDBK-217F
42g (1.46 oz) Conducted immunity
4.632 x 10
5
hrs
EN61000-4-6
10 Vr.m.s
Page 1 of 3
www.pduke.com
±
Case material
EN61000-4-5
±
IEC60950-1 EMI (Note 8)
UL60950-1
EN60950-1 Radiated immunity
Fast transient (Note 9)
Aluminum base-plate Surge (Note 9)
±
ENVIRONMENTAL SPECIFICATIONS
Operating base-plate temperature range (Note 7)
-40ºC ~ +100ºC
+110ºC
-55ºC ~ +125ºC
MIL-STD-810F
MIL-STD-810F
5% to 95% RH
See table Over temperature protection
EMC CHARACTERISTICS
EN55022
EN61000-4-3
EN61000-4-4
10 V/m
2kV
1kV
Class A, Class B
Perf. Criteria A
Perf. Criteria B
Perf. Criteria B
Perf. Criteria A
2014/4/30
QEB75 SERIES
75 WATTS
DC-DC CONVERTER
Model
Number
QEB75-24S3P3
QEB75-24S05
QEB75-24S12
QEB75-24S15
QEB75-48S1P8
QEB75-48S2P5
QEB75-48S3P3
QEB75-48S05
QEB75-48S12
QEB75-48S15
Input
Range
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
18 ~ 36 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
36 ~ 75 VDC
Output
Voltage
3.3 VDC
5 VDC
12 VDC
15 VDC
1.8 VDC
2.5 VDC
3.3 VDC
5 VDC
12 VDC
15 VDC
Output Current
Min. load
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
0mA
Full load
20A
15A
6.25A
5A
25A
25A
20A
15A
6.25A
5A
Output
Ripple & Noise
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
100mVp-p
(2)
No load
Input Current
65mA
110mA
40mA
50mA
60mA
50mA
70mA
80mA
50mA
50mA
(3)
Eff(%)
89
90
90
90
85
87
90
90
90
90
(4)
Note :
1. MIL-HDBK-217F @Tc=70 ºC, Full load.
2. Typical value at nominal input and full load. (20MHZ BW)
3. Typical value at nominal input and no load.
4. Typical value at nominal input and full load.
5. Maximum output deviation is 10% inclusive of trim. If remote sense is not being used, the +SENSE should be connected to its corresponding
+OUTPUT and likewise the -SENSE should be connected to its corresponding –OUTPUT.
6. The positive logic and pin length are optional ( see table ). The CTRL pin voltage is referenced to -INPUT.
7. Heat-sink is optional and P/N 7G-0029A-F, 7G-0030A-F, 7G-0031A-F, 7G-0032A-F.
8. The QEB75 series standard module meets EN55022 Class A and Class B with external components.
For more detail information, please contact with P-DUKE.
9. An external input filter capacitor is required if the module has to meet EN61000-4-4, EN61000-4-5.
The filter capacitor Power Mate suggest: Nippon chemi-con KY series, 220 F/100V.
10. BASE-PLATE GROUNDING When connect the four screw bolts to shield plane, the EMI could be reduced.
11. The converter is provided by basic insulation.
CAUTION:
This power module is not internally fused. An input line fuse must always be used.
QEB75-48S05 Derating Curve
120
100
OUTPUT POWER(%)
OUTPUT POWER(%)
80
60
40
20
0
-40
-20
0
20
40
60
80
AMBIENT TEMPERATURE,TA( )
100
120
Natural Convection
100LFM
200LFM
300LFM
400LFM
500LFM
24
QEB75-48S05 Efficiency VS Voltage
93
92
EFFICIENCY(%)
QEB75-48S05 Efficiency VS Output Load
95
90
EFFICIENCY(%)
85
80
75
70
65
91
90
89
88
87
36
40
44
48
52
56
60
64
INPUT VOLTAGE(V)
68
72
75
10
20
30
40
50
60
70
% of FULL LOAD
80
Page 2 of 3
www.pduke.com
℃
μ
℃
：
：
QEB75-48S05 Derating Curve
With Heat-sink 7G-0029(Note 7)
120
100
80
60
40
20
0
-40
-20
0
20
40
60
80
AMBIENT TEMPERATURE,TA( )
100
120
Natural Convection
100LFM
200LFM
300LFM
400LFM
34
500LFM
90
100
2014/4/30
QEB75 SERIES
75 WATTS
DC-DC CONVERTER
PIN CONNECTION
）
）
）
）
）
）
）
）
（
（
（
（
（
（
（
（
PIN
1
2
3
4
5
6
7
8
DEFINE
-INPUT
CTRL
+INPUT
-OUTPUT
-SENSE
TRIM
+SENSE
+OUTPUT
DIAMETER
0.040 Inch 1.02mm
0.040 Inch 1.02mm
0.040 Inch 1.02mm
0.060 Inch 1.52mm
0.040 Inch 1.02mm
0.040 Inch 1.02mm
0.040 Inch 1.02mm
0.060 Inch 1.52mm
Remote On/Off and Pin Options
Negative remote ON/OFF logic, 0.200” pin length (standard)
Negative remote ON/OFF logic, 0.145” pin length
Positive remote ON/OFF logic, 0.200” pin length
Positive remote ON/OFF logic, 0.145” pin length
Example QEB75-48S3P3-PHS
* The module can’t equip heat-sink with TH option.
Page 3 of 3
：
：
：
：
1. All dimensions in Inch (mm)
Tolerance: X.XX±0.02 (X.X±0.5)
X.XXX±0.01 (X.XX±0.25)
2. Pin pitch tolerance ±0.01(0.25)
3. Pin dimension tolerance ±0.004 (0.1)
MECHANICAL DRAWING
EXTERNAL OUTPUT TRIMMING
Output can be externally trimmed by
using the method shown below.
TRIM UP
TRIM DOWN
7
6
R
U
6
5
R
D
Suffix
-
-L
-P
-S
Heat-Sink and Mounting Hole Tread Options
Without heat-sink
7G-0029A-F
7G-0030A-F
7G-0031A-F
7G-0032A-F
Through hole (No thread)
Suffix
-
-HS
- HS1
- HS2
- HS3
-TH
：
www.pduke.com
2014/4/30
