H-20XC-X

Description
BI-LEVEL T-1 (3mm) LED HOLDER INTERLOCKING VARIABLE DIAMETER
File Size35KB,1 Pages
ManufacturerETC2
Download Datasheet Compare View All

H-20XC-X Overview

BI-LEVEL T-1 (3mm) LED HOLDER INTERLOCKING VARIABLE DIAMETER

REV.
DESCRIPTION
DATE
APPROVED
B
Engineering Update w/o Changes
02/27/04
M. C.
0.100 [2.5mm]
TYP.
0.023 [0.6mm] SQ.
TYP.
0.320 [8.1mm]
0.100 [2.5mm]
0.180 [4.6mm]
0.300 [7.6mm]
0.100 [2.5mm]
DIA
TYP.
Cathode I.D.
Mark
0.185 [4.7mm]
0.285 [7.2mm]
Holder Faces
0.380 [9.7mm]
0.120 [3.0mm]
0.195 [5.0mm]
Ø.032+.003
-.002
TYP.
0.100 [2.5mm]
0.182 [4.6mm]Holder Pitch
0.100 [2.5mm] LED Lead
Recommended Mounting Holes
H-200C
H-201C
DIA
H-202C
H-203C
PART NO.
H-200C SERIES H-201C SERIES H-202C SERIES H-203C SERIES
H-200C
H-200C-1
H-201C
H-201C-1
H-202C
H-202C-1
H-203C
H-203C-1
.128 [3.3mm]
.150 [3.8mm]
STANDARD TOLERANCE
( UNLESS OTHERWISE SPECIFIED )
DECIMALS
ANGULAR
®
2. MATERIAL: NYLON 6/6, 94V-0, BLACK. BIVAR MATERIAL CODE 22-BK.
RTP POLYAMIDE NYLON 6/6, 0200 FR, BLACK OR MODIFIED PLASTICS MN6/6-SE BK.
1. GENERAL SPECIFICATIONS: BIVAR MOLDED COMPONENT SPECIFICATION BV00-E101.
.X
.XX
.XXX
DESIGNED:
± .1
± .01
± .005
± 1°
4 THOMAS, IRVINE, CA. 92618
TEL: (949) 951-8808
FAX: (949) 951-3974
DATE:
TITLE:
BI-LEVEL T-1 (3mm) LED HOLDER
INTERLOCKING VARIABLE DIAMETER
REVISION:
PART NO:
David Green
CHECKED:
03/13/03
DATE:
H-20XC-X
B
CAGE CODE : 32559
SHEET #
1
OF
1
M. Chen
03/13/03
CAD GENERATED DOCUMENT, DO NOT MEASURE DRAWING.
