6W Pure Green &Red & Blue Star MCPCB
OSTCXBCBC1E
VER.A.3
■
Features
●
■
Outline
Dimension
Highest luminous flux
Super energy efficiency
Very long operating life
Superior ESD protection
Superior UV Resistance
G
R
B
●
●
●
●
■
Applications
●
Top View
Side View
Unit:mm
Tolerance:±0.30mm
Small Area Illuminations
Games
Bollards / Security / Garden
Audio
Back View
●
●
●
■
Absolute
Maximum Rating
Symbol
I
F
I
FP
V
R
P
D
Topr
Tstg
Tsol
Item
DC Forward Current
Pulse Forward Current*
Reverse Voltage
Power Dissipation
Operating Temperature
Storage Temperature
Lead Soldering Temperature
Red
600
800
5
2,100
(Ta=25℃)
Value
Green/Blue
600
800
5
2,700
-30 ~ +85
-40 ~ +100
260
℃
/5sec
■
Directivity
Unit
mA
mA
V
mW
0
℃
℃
-
0
*Pulse width Max.10ms Duty ratio max 1/10
■
Electrical
-Optical Characteristics
Symbol
V
F
(
R
)
V
F
(
B/G
)
(Ta=25℃)
Min.
2.5
3.5
-
619
520
455
40
80
20
-
Item
DC Forward Voltage
DC Reverse Current
Domi. Wavelength
Condition
I
F
=500mA
I
F
=500mA
V
R
=5V
I
F
=500mA
I
F
=500mA
I
F
=500mA
I
F
=500mA
I
F
=500mA
I
F
=500mA
I
F
=500mA
Typ.
3.0
4.0
-
624
525
460
50
90
25
120
Max.
3.5
4.5
10
629
535
465
60
100
30
Unit
V
V
µA
nm
nm
nm
lm
lm
lm
deg
I
R
λ
D
(Red)
λ
D
(Green)
λ
D
(Blue)
Φv
(Red)
Luminous Flux
50% Power Angle
Φv
(Green)
Φv
(Blue)
2θ
1/2
Note: *1. Tolerance of chromaticity coordinates is
±10%
*3. Tolerance of luminous Flux is
±15%
*2. Dominant wavelength tolerance: ±1nm
*4 Don’t drive at rated current more than 5s without heat sink for Xeon 1 Power emitter series.
