Wall Industries, Inc.
Rev A
PSSBU99 SERIES
100 Watt AC/DC Open Frame Power Supplies
FEATURES
•
Class I
•
RoHS Compliant
•
Internal EMI Filter
•
100 Watts Output Power
•
Active Power Factor Correction
•
100% Burn-in Tested
•
Single Output Voltages Available from 11VDC to 55VDC
•
Over Voltage Protection (Crowbar Design)
•
Input Surge Current, Over Voltage, and Over Load Protection
•
Wide Input Voltage Range: 90~264VAC, 47~63Hz
•
Meets FCC Part-15 Class B and CISPR-22 Class B Emission Limits
•
UL/cUL(UL 60950-1:2nd Edition) Safety Approvals
DESCRIPTION
The PSSBU99 series of Class I AC/DC switching mode power supplies provides 100 Watts of continuous output
power in a 4.00” x 2.00” x 1.09” open frame package. This series consists of single output models ranging from
11VDC to 55VDC with a wide input voltage range of 90~264VAC. These power supplies have active PFC, an internal
EMI filter, and over load, over voltage, and input surge current protection. This series also has UL/cUL (UL 60950-1:
2nd edition) safety approvals and meets FCC Part-15 class B and CISPR-22 Class B emission limits. These supplies are
well suited for use in industrial equipment as well as many other applications.
Size:
Weight:
4.00 x 2.00 x 1.09 inches 6.3~8.8oz (180~250g)
TECHNICAL SPECIFICATIONS: PSSBU99 SERIES
All specifications are based on 25°C, Nominal Input Voltage, and Maximum Output Current unless otherwise noted.
We reserve the right to change specifications based on technological advances.
SPECIFICATION
INPUT SPECIFICATIONS
Input Voltage
Input Frequency
Input Current
Inrush Current
No Load Power Consumption
Power Factor Correction
OUTPUT SPECIFICATIONS
Output Voltage
Line Regulation
Load Regulation
Output Power
Output Current
Ripple & Noise (peak to peak)
Hold-up Time
Start-up Time
Transient Response Time
Temperature Coefficient
PROTECTION
Over Voltage Protection
Over Current Protection
GENERAL SPECIFICATIONS
Efficiency
Dielectric Withstanding Voltage
Isolation Resistance
Leakage Current
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Cooling
MTBF
PHYSICAL SPECIFICATIONS
Weight
Dimensions (L x W x H)
Input Connector
Output Connector
SAFETY & EMC
Safety Approvals
EMI Requirements for CISPR-22
EMI Requirements for FCC PART-15
TEST CONDITIONS
Safety Approvals Input Voltage Range
Operating Input Voltage Range
100VAC, full load
240VAC, full load
115VAC, full load, 25°C, cold start
230VAC, full load, 25°C, cold start
230VAC, no load
240VAC, full load
Min
100
90
47
Typ
Max
240
264
63
1.4
0.7
50
100
0.5
1
Unit
VAC
Hz
A
A
W
0.95
See Table
LL to HL, full load
230VAC
1
See Table
100
See Table
1
16
1
4
+0.04
132
150
91
%
W
%
ms
s
ms
%/°C
%
%
%
VDC
0.75
0
-40
0
0
100,000
+70
+85
95
95
Free air convection
MΩ
mA
°C
°C
%
%
hours
90VAC, full load
110VAC, full load
100VAC, full load
100VAC, Full load to half load
0~50°C
-0.04
112
110
230VAC, full load
Primary to Secondary
Primary to PE
Test Voltage = 500VDC
240VAC/60Hz
Derating linearly from 100% Load at 25°C to 50% load at 70°C
87
4242
2121
50
MIL-HDBK-217F, 25°C
6.3~8.8oz (180~250g)
4.00 x 2.00 x 1.09 inches (138.0 x 87.0 x 44.6 mm)
Mates with JST housing VHR-3N and JST SVH series crimp terminal
Mates with JST housing VHR-6N and JST SVH series crimp terminal
UL/cUL (UL 60950-1: 2
nd
edition)
B
Class
B
Class
220VAC
110VAC
05/27/2014
Wall Industries, Inc. • 37 Industrial Drive, Exeter, NH 03833 • Tel: 603-778-2300 • Toll Free: 888-597-9255 • Fax 603-778-9797
website: www.wallindustries.com • e-mail: sales@wallindustries.com
Page 1 of 3
Wall Industries, Inc.
Rev A
PSSBU99 SERIES
100 Watt AC/DC Open Frame Power Supplies
MODEL SELECTION TABLE
Model Number
PSSBU99-105
PSSBU99-106
PSSBU99-107
PSSBU99-108
PSSBU99-109
PSSBU99-110
PSSBU99-111
PSSBU99-112
90 ~ 264 VAC
Input Voltage Range
Output Voltage
11 ~ 13 VDC
13 ~ 16 VDC
16 ~ 21 VDC
21 ~ 27 VDC
27 ~ 33 VDC
33 ~ 40 VDC
40 ~ 50 VDC
50 ~ 55 VDC
Output Current
8.33 ~ 7.69 A
7.69 ~ 6.25 A
6.25 ~ 4.76 A
4.76 ~ 3.70 A
3.70 ~ 3.03 A
3.03 ~ 2.50 A
2.50 ~ 2.00 A
2.00 ~ 1.81 A
Total Regulation
3%
3%
3%
2%
2%
2%
2%
2%
Ripple & Noise
1%
1%
1%
1%
1%
1%
1%
1%
Output Power
100W
100W
100W
100W
100W
100W
100W
100W
DERATING CURVE
100
80
Output Power (%)
60
40
20
0
0
10
20
30
40
50
60
70
80
Ambient Temperature (°C)
MECHANICAL DRAWING
4.00 [101.6]
0.16 [4.0]
3.69 [93.6]
PIN CONNECTIONS
Pitch = 0.31 [7.92]
Pin
Designation
OUT
OUT
OUT
RTN
RTN
RTN
Pitch = 0.16 [3.96]
1
2
3
4
5
6
AC
INPUT
N
L
P1
0.69 [17.6]
Ø0.16 [Ø4.0] MOUNTING HOLES X 4
2.00 [50.8]
NOTES
1.
Unit: inches [mm]
0.12 [3.0]
2.
Tolerance:
±0.02 [±0.5]
3.
Weight: 6.3~8.8oz (180~250g)
4.
Input connector mates with JST housing VHR-3N and JST SVH series crimp terminal.
5.
Output connector mates with JST housing VHR-6N and JST SVH series crimp terminal.
6.
All dimensions are for reference only
0.06 [1.6]
05/27/2014
Wall Industries, Inc. • 37 Industrial Drive, Exeter, NH 03833 • Tel: 603-778-2300 • Toll Free: 888-597-9255 • Fax 603-778-9797
website: www.wallindustries.com • e-mail: sales@wallindustries.com
0.52 [13.3]
6
5
4
3
2
1
P2
2.00 [50.8]
1.69 [42.8]
DC
OUTPUT
Page 2 of 3
Wall Industries, Inc.
Rev A
PSSBU99 SERIES
100 Watt AC/DC Open Frame Power Supplies
COMPANY INFORMATION
Wall Industries, Inc. has created custom and modified units for over 50 years. Our in-house research and development engineers will provide a
solution that exceeds your performance requirements on-time and on budget. Our ISO9001-2008 certification is just one example of our
commitment to producing a high quality, well-documented product for our customers.
Our past projects demonstrate our commitment to you, our customer. Wall Industries, Inc. has a reputation for working closely with its customers to
ensure each solution meets or exceeds form, fit and function requirements. We will continue to provide ongoing support for your project above and
beyond the design and production phases. Give us a call today to discuss your future projects.
Contact
Wall Industries
for further information:
Phone:
Toll Free:
Fax:
E-mail:
Web:
Address:
(603)778-2300
(888)597-9255
(603)778-9797
sales@wallindustries.com
www.wallindustries.com
37 Industrial Drive
Exeter, NH 03833
05/27/2014
Wall Industries, Inc. • 37 Industrial Drive, Exeter, NH 03833 • Tel: 603-778-2300 • Toll Free: 888-597-9255 • Fax 603-778-9797
website: www.wallindustries.com • e-mail: sales@wallindustries.com
Page 3 of 3
