SAK-XC164TM-8F40F datasheet, PDF

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAK-XC164TM-8F40F

SAK-XC164TM-8F40F: DescriptionMicrocontroller, 16-Bit, FLASH, 40MHz, CMOS, PQFP64, PLASTIC, TQFP-64; CategoryThe embedded processor and controller Microcontrollers and processors; File Size602KB，65 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

SAK-XC164TM-8F40F Overview

Microcontroller, 16-Bit, FLASH, 40MHz, CMOS, PQFP64, PLASTIC, TQFP-64

SAK-XC164TM-8F40F Parametric

Parameter Name	Attribute value
Maker	Infineon
Parts packaging code	QFP
package instruction	PLASTIC, TQFP-64
Contacts	64
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Has ADC	YES
Other features	ALSO REQUIRES 5V SUPPLY
Address bus width
bit size	16
maximum clock frequency	40 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G64
length	10 mm
Number of I/O lines	47
Number of terminals	64
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
Certification status	Not Qualified
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	40 MHz
Maximum supply voltage	2.7 V
Minimum supply voltage	2.35 V
Nominal supply voltage	2.5 V
surface mount	YES
technology	CMOS
Temperature level	AUTOMOTIVE
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

Preview

Download Datasheet

View All

D a t a S h e et , V 1 . 0 , N o v . 2 0 0 5

XC164TM

1 6 - B i t S i n g l e - C h i p M i c ro c o n t r o ll e r

w it h C 1 6 6 S V 2 C o r e

M i c r o c o n t r o l l e rs

N e v e r

s t o p

t h i n k i n g .

XC164TM

Derivatives

Table of Contents

2.1

3.1

3.2

3.3

3.4

3.5

3.6

3.7

3.8

3.9

3.10

3.11

3.12

3.13

3.14

3.15

4.1

4.2

4.3

4.4

4.4.1

4.4.2

4.4.3

5.1

5.2

5.3

Summary of Features

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

General Device Information

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Pin Configuration and Definition . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Functional Description

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Memory Subsystem and Organization . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Central Processing Unit (CPU) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Interrupt System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-Chip Debug Support (OCDS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Capture/Compare Unit (CAPCOM2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Purpose Timer (GPT12E) Unit . . . . . . . . . . . . . . . . . . . . . . . . . . .

Real Time Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

A/D Converter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Asynchronous/Synchronous Serial Interfaces (ASC0/ASC1) . . . . . . . . . .

High Speed Synchronous Serial Channels (SSC0/SSC1) . . . . . . . . . . . .

Watchdog Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Clock Generation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Parallel Ports . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Instruction Set Summary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Electrical Parameters

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

General Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

DC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Analog/Digital Converter Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . .

AC Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Definition of Internal Timing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

On-chip Flash Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

External Clock Drive XTAL1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Package and Reliability

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Packaging . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Flash Memory Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Quality Declarations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Data Sheet

V1.0, 2005-11
