SHEET 1 OF 1
36.80
[1.449 in]
43.20
[1.701 in]
21.00
[.827 in]
24.50
[.965 in]
SUGGESTED PANNELL CUTOUT
MAX PANEL THICKNESS 6.0mm
POS. 3
SWITCH FUNCTION
3
1
POS. 3
POS. 2
POS. 1
6.60
`
.50
[.260
`
.020
in]
POS. 2
POS. 1
ACTUATOR COLOR
BLACK MATT FINISH
BODY COLOR
BLACK MATT FINISH
17.00
[.669 in]
2
CURCUIT: SPDT
ON
2-1
OFF
OPEN
ON
2-3
2.00
[.079 in]
28.30
[1.114 in]
38.70
`
.50
[1.524
`
.020
in]
NOTES:
1. ALL DIMESNSIONS IN MM [INCH]
2. GENERAL TOLERANCE: X.X=
`
0.4
X.XX=
`
0.25
3. RATINGS: ANSI/UL 508 AND CAN/CSA C22.2 NO.14 (E195908):
20A, 125VAC [cURus]
15A, 277VAC [cURus]
B
2HP, 110/250VAC [cURus]
4. CONTACT RESISTANCE: 50 mΩ MAX. @ 50VAC
5. INSULATION RESISTANCE: 800 MΩ MIN. @ 500VDC
6. OPERATING TEMPERATURE: -20°C TO +65°C [cURus, CSA]
-20°C TO +125°C [VDE]
7. ELECTRICAL LIFE: 6,000 [cURus]
8. DIELECTRIC STRENGTH: 1,500V FOR 1 MINUTE
9. OPERATING TEMPERATURE: -20°C TO 55°C [cURus]
10. INGRESS PROTECTION: IP54
11.
DENOTES CRITICAL PARAMETER
12. 2002/95/EC (RoHS) COMPLIANT.
3
6.30
[.248 in]
2
1
n
1.70
[.067 in]
1
19.50
[.768 in]
20.60
[.811 in]
36.70
`
.50
[1.445
`
.020
in]
.80
[.031 in]
B
A
REV
20444
20421
PCR NO
CORRECT 2HP RATING
RELEASE FOR PRODUCTION
DESCRIPTION
1/31/12
1/24/12
DATE
BGL
BGL
BY
TITLE
SCALE
RVW45D1100
DATE
THE INFORMATION CONTAINED IN THIS DOCUMENT IS PROPRIETARY
TO E-SWITCH AND IS NOT TO BE COPIED OR TRANSFERRED
1:1
1/24/2012
BGL
DR
34-RVW45D1100
DWG
REV
B
