Extreme Temperature Silicon
Capacitor
The IPDiA Technology features a Capacitor Integration
Capability (up to 250nF/mm
2
) which allows a capacitance
value similar to X8R dielectric, but with better electrical
performances than C0G/NP0 dielectrics.
This technology also offers high reliability, up to 10 times
better than alternative capacitor technologies.
This silicon based technology is RoHS compliant and
compatible with lead free reflow soldering process.
XTSC1812 3.3µF
935.133.429.733
Pb
Key Features
• Ultra Low Profile (100µm)
• Ultra High Temperature up to 250°C;
• Temperature Coeff<±1.5% (-55 to +250°C)
• Voltage < 0.1 % / V
• Negligible Capacitance Loss through Ageing
• Unique High Capacitance in EIA/0402 Package Size, up to
100nF
• High Reliability (FIT < 0.017 parts / billion hours)
• Low Leakage Current down to 100pA
• Low ESL and Low ESR
• Suitable with Lead Free Reflow-Soldering
Key Applications
• 250°C
Requirements, High Temperature
Applications, such
as Military, Aerospace, Automotive & Downhole Industries.
• High Reliability Applications
• Decoupling / Filtering / Charge Pump (ie. Pressure Sensor,
Motor Managment)
• Replacement of X8R and C0G Dielectrics
• Downsizing
Part Number
935.132.
935.133.424.547
B. 2
Breakdown
Voltage:
4 = 11V
7 = 30V
S.
Size:
2 = 1005
3 = 0201
4 = 0402
U.
Unit:
0 = 10f
1 = 0.1p
2 = 1p
3 = 10p
4 = 0.1n
5 = 1n
6 = 10n
7 = 0.1u
8 = 1u
9 = 10u
xx
Value
ie. 47nF/0402 case (XTSC type)
Parameters
Capacitance Range 100pF to 100nF
Capacitance Tolerances ±15%
Operating Temperature Range -55°C to 250°C
Storage Temperatures -70°C to 265°C
Value
Temperature Coefficient <±1.5%, from -55°C to +250°C
Breakdown Voltage (BV) 11VDC, 30VDC
Capacitance Variation Vs. RVDC 0.1%
IV
(from 0 V to RVDC)
Equivalent Serial Inductor (ESL) Max 100pH
Equivalent Serial Resistor (ESR) Max 400mΩ
Insulation Resistance 50GΩ min @ 3V,25°C
10GΩ min @ 3V, 250°C
Ageing Negligible, < 0.001% / 1000h
Reliability FIT < 0.017 parts / billion hours
Capacitor Height Max 400µm
