This document was generated on 10/03/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
34566-2003
Active
MX123™ Sealed Connection System
2.54mm Pitch, MX123™ Female Receptacle Housing, Keying Option H, Wire Dress
Option 9, 80 Circuits, Gray TPA
Documents:
3D Model
Drawing (PDF)
Product Specification PS-34566-0000 (PDF)
Application Specification AS-34566-001 (PDF)
Test Summary TS-34566-002 (PDF)
RoHS Certificate of Compliance (PDF)
image - Reference only
Series
General
Product Family
Series
Application
Comments
Overview
Product Name
UPC
Crimp Housings
34566
Power, Wire-to-Board
See Sales Drawing for number of Open Circuits
MX123™ Sealed Connection System
MX123
822350127776
EU RoHS
ELV and RoHS
Compliant
REACH SVHC
Contains SVHC: No
Low-Halogen Status
Low-Halogen
China RoHS
Physical
Circuits (maximum)
Circuits Detail
Color - Resin
Gender
Glow-Wire Compliant
Keying to Mating Part
Lock to Mating Part
Material - Resin
Net Weight
Number of Rows
Packaging Type
Panel Mount
Pitch - Mating Interface
Pitch - Termination Interface
Polarized to Mating Part
Stackable
Temperature Range - Operating
80
80
Gray
Female
No
Yes
Yes
Nylon
51.245/g
4
Tray
No
2.54mm
2.54mm
Yes
No
-40°C to +125°C
Need more information on product
environmental compliance?
Email productcompliance@molex.com
For a multiple part number RoHS Certificate of
Compliance, click here
Please visit the Contact Us section for any
non-product compliance questions.
Search Parts in this Series
34566Series
Mates With
MX123™ Header 31386 , 31387
Use With
MX64™ Female Terminals 33467
Electrical
Current - Maximum per Contact
11A, 25A
Material Info
Old Part Number
CVP34566-2003
Reference - Drawing Numbers
Application Specification
Product Specification
Test Summary
AS-34566-001
PS-34566-0000
TS-34566-002
This document was generated on 10/03/2014
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
